Aardvark AVP Rotary Vane Pump

Name: Aardvark AVP Rotary Vane Pump
Brand: AB Industrial
SKU: POS-6519a5
Price: 799.99 USD
Availability: OutOfStock

SKU:POS-6519a5

Reliable Aardvark AVP Rotary Vane Pump for clean low flow applications with medium to high pressure requirements. Features durable construction, versatile motor options, and maximum 250 psi pressure capacity.

$799.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The Aardvark AVP Rotary Vane Pump is a reliable solution for clean low flow applications with medium to high pressure requirements. Featuring a durable construction with options for Bronze or 303SS housing, stainless steel shaft, self-adjusting carbon vanes, and various seal material choices including Buna, EPDM, Neoprene, and Viton. This pump is equipped with Stainless Steel Internal Bypass Relief Valve, FNPT Ports, and versatile motor options such as AC, DC, Air, or Hydraulic. With a maximum pressure of 250 psi, variable speed capabilities, and a range of power and voltage options, the Aardvark AVP Rotary Vane Pump ensures efficient and precise operation in diverse settings.

Product Specifications

Specifications Coupling Type

Flex

Specifications Discharge

1/2 in

Specifications Driver

AC Motor | Air Motor | DC Motor | Hydraulic Motor

Specifications Frequency

50 Hz | 60 Hz | DC Hz

Specifications Gallons Per Revolution

0.096 Gal/rev

Specifications Gph

165 gph

Specifications Housing Material

303SS | Bronze

Specifications Manufacturer

AARDVARK

Specifications Maximum Gallons Per Hour

210 gph

Specifications Maximum Pressure

250 psi

Specifications Maximum Speed

2000 rpm

Specifications Minimum Gallons Per Hour

55 gph

Specifications Minimum Speed

600 rpm

Specifications Motor Enclosure

Explosion Proof | Hostile Duty | Stainless Steel | TEFC | Washdown

Specifications Phase

1 | 3

Specifications Port Configuration

Specifications Port Type

FNPT

Specifications Power

1/2 hp | 1/3 hp | 3/4 hp

Specifications Seal Material

Buna | EPDM | Neoprene | Viton

Specifications Speed

1725 rpm

Specifications Suction

1/2 in

Specifications Voltage

110 V | 12 V | 180 V | 190 V | 200 V | 230 V | 24 V | 380 V | 460 V | 575 V | 90 V

Aardvark AVP Rotary Vane Pump
