Aardvark AVP Rotary Vane Pump
Aardvark AVP Rotary Vane Pump
SKU:POS-32054c
Reliable Aardvark AVP Rotary Vane Pump for clean low flow & medium pressure applications, self-adjusting carbon vanes, various motor drives, VFD compatibility.
Regular price
$1,299.99
Regular price
Sale price
$1,299.99
Unit price
per
Initiate Order
Aardvark AVP Rotary Vane Pump
$1,299.99
Quantity: 1
Claim Your Seller Account
Aardvark AVP Rotary Vane Pump
$1,299.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Aardvark AVP Rotary Vane Pump is a reliable solution for clean low flow and medium pressure positive displacement applications. With a maximum capacity of 11 GPM (660 GPH) at 125 psi, this pump features self-adjusting carbon vanes, bearings, and wear plates for durability. The modular construction offers housing options in 303SS or Bronze with a Stainless Steel shaft, along with a Stainless Steel internal bypass relief valve. It is equipped with Neodymium & Samarium Cobalt magnetic couplings, various motor drive options including AC, DC, air, or hydraulic, and compatibility with Variable Frequency Drives for enhanced control.
Product Specifications
Specifications Coupling Type
Mag Drive
Specifications Discharge
0.5 in | SAE 10 in
Specifications Driver
AC Motor | Air Motor | DC Motor | Hydraulic Motor
Specifications Frequency
50 Hz | 60 Hz | DC Hz
Specifications Gallons Per Revolution
0.125 Gal/rev
Specifications Gph
215 gph
Specifications Housing Material
303SS | Bronze
Specifications Manufacturer
AARDVARK
Specifications Maximum Gallons Per Hour
273 gph
Specifications Maximum Pressure
180 psi
Specifications Maximum Speed
2000 rpm
Specifications Minimum Gallons Per Hour
72 gph
Specifications Minimum Speed
600 rpm
Specifications Motor Enclosure
Explosion Proof | Hostile Duty | IEEE 841 | Stainless Steel | TEFC | Washdown
Specifications Phase
1 | 3
Specifications Port Configuration
U
Specifications Port Type
FNPT
Specifications Power
1 hp | 1/2 hp | 1/3 hp | 3/4 hp
Specifications Seal Material
Buna | EPDM | Neoprene | Viton
Specifications Speed
1725 rpm
Specifications Suction
0.5 in | SAE 10 in
Specifications Voltage
110 V | 12 V | 180 V | 190 V | 200 V | 230 V | 24 V | 380 V | 460 V | 575 V | 90 V
