Aardvark AVP Rotary Vane Pump
Aardvark AVP Rotary Vane Pump
SKU:POS-f8e35b
Reliable Aardvark AVP Rotary Vane Pump for clean low flow and medium pressure applications. Various motor drive options & versatile performance.
Regular price
$1,299.99
Regular price
Sale price
$1,299.99
Unit price
per
Initiate Order
Aardvark AVP Rotary Vane Pump
$1,299.99
Quantity: 1
Claim Your Seller Account
Aardvark AVP Rotary Vane Pump
$1,299.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Aardvark AVP Rotary Vane Pump is a reliable solution for clean low flow and medium pressure positive displacement applications. With a capacity ranging from 0.1 to 11 GPM (5 to 660 GPH) and a maximum pressure of 180 psi, this pump features sturdy construction including bronze or 303SS housing options with a stainless steel shaft, self-adjusting carbon vanes, bearings, and wear plates. The pump is equipped with a stainless steel internal bypass relief valve, Neodymium & Samarium Cobalt magnetic couplings, and offers various motor drive options including AC, DC, air, or hydraulic motors. It is versatile with variable speed capabilities and compatibility with VFD (Variable Frequency Drives). Secure your fluid transfer needs with the Aardvark AVP Rotary Vane Pump.
Product Specifications
Specifications Coupling Type
Mag Drive
Specifications Discharge
3/8 in
Specifications Driver
AC Motor | Air Motor | DC Motor | Hydraulic Motor
Specifications Frequency
50 Hz | 60 Hz | DC Hz
Specifications Gallons Per Revolution
0.035 Gal/rev
Specifications Gph
60 gph
Specifications Housing Material
303SS | Bronze
Specifications Manufacturer
AARDVARK
Specifications Maximum Gallons Per Hour
76 gph
Specifications Maximum Pressure
180 psi
Specifications Maximum Speed
2000 rpm
Specifications Minimum Gallons Per Hour
20 gph
Specifications Minimum Speed
600 rpm
Specifications Motor Enclosure
Explosion Proof | Hostile Duty | Stainless Steel | TEFC | Washdown
Specifications Phase
1 | 3
Specifications Port Configuration
U
Specifications Port Type
FNPT
Specifications Power
1/2 hp | 1/3 hp
Specifications Seal Material
Buna | EPDM | Neoprene | Viton
Specifications Speed
1725 rpm
Specifications Suction
3/8 in
Specifications Voltage
110 V | 12 V | 180 V | 190 V | 200 V | 230 V | 24 V | 380 V | 460 V | 575 V | 90 V
