Aardvark AVP Rotary Vane Pump

Name: Aardvark AVP Rotary Vane Pump
Brand: AB Industrial
SKU: POS-f213db
Price: 799.99 USD
Availability: OutOfStock

SKU:POS-f213db

Enhance your operations with the Aardvark AVP Rotary Vane Pump - ideal for low flow, medium-pressure applications. Self-adjusting carbon vanes, multiple motor drive options, and variable speed capabilities.

$799.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The Aardvark AVP Rotary Vane Pump is a cost-effective solution designed for clean, low flow, and medium-pressure positive displacement applications. With a modular construction, this pump features a range of 0.1 to 11 GPM (5 to 660 GPH) at a maximum pressure of 125 psi. It incorporates self-adjusting carbon vanes, bearings, and wear plates for enhanced durability. The pump also comes with a stainless steel internal bypass relief valve, Neodymium & Samarium Cobalt magnetic couplings, and various motor drive options including AC, DC, air, and hydraulic. Suitable for diverse settings, it offers variable speed capabilities and is compatible with Variable Frequency Drives (VFD).

Product Specifications

Specifications Coupling Type

Mag Drive

Specifications Discharge

0.5 in | SAE 10 in

Specifications Driver

AC Motor | Air Motor | DC Motor | Hydraulic Motor

Specifications Frequency

50 Hz | 60 Hz | DC Hz

Specifications Gallons Per Revolution

0.081 Gal/rev

Specifications Gph

140 gph

Specifications Housing Material

303SS | Bronze

Specifications Manufacturer

AARDVARK

Specifications Maximum Gallons Per Hour

178 gph

Specifications Maximum Pressure

180 psi

Specifications Maximum Speed

2000 rpm

Specifications Minimum Gallons Per Hour

47 gph

Specifications Minimum Speed

600 rpm

Specifications Motor Enclosure

Explosion Proof | Hostile Duty | Stainless Steel | TEFC | Washdown

Specifications Phase

1 | 3

Specifications Port Configuration

Specifications Port Type

FNPT

Specifications Power

1/2 hp | 1/3 hp | 3/4 hp

Specifications Seal Material

Buna | EPDM | Neoprene | Viton

Specifications Speed

1725 rpm

Specifications Suction

0.5 in | SAE 10 in

Specifications Voltage

110 V | 12 V | 180 V | 190 V | 200 V | 230 V | 24 V | 380 V | 460 V | 575 V | 90 V

Aardvark AVP Rotary Vane Pump
