Aardvark AVP Rotary Vane Pump
Aardvark AVP Rotary Vane Pump
SKU:POS-30fc67
Reliable Aardvark AVP Rotary Vane Pump for clean low flow & medium pressure applications. Featuring self-adjusting carbon vanes, stainless steel construction & variable speed options.
Regular price
$999.99
Regular price
Sale price
$999.99
Unit price
per
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.

The Aardvark AVP Rotary Vane Pump is a reliable solution for clean low flow and medium pressure positive displacement applications. Built with a standard modular construction, this pump features a range of 0.1 to 11 GPM (5 to 660 GPH) at a maximum pressure of 125 psi. It is equipped with self-adjusting carbon vanes, bearings, and wear plates for durability. The pump boasts a stainless steel internal bypass relief valve, Neodymium & Samarium Cobalt magnetic couplings, and offers various motor drive options including AC, air, DC, or hydraulic. With its variable speed and VFD compatibility, this pump provides versatility and efficiency for a wide range of pumping needs.
Product Specifications
Specifications Coupling Type
Flex
Specifications Discharge
SAE 16 in
Specifications Driver
AC Motor | Air Motor | DC Motor | Hydraulic Motor
Specifications Frequency
50 Hz | 60 Hz | DC Hz
Specifications Gallons Per Revolution
0.174 Gal/rev
Specifications Gph
300 gph
Specifications Housing Material
303SS
Specifications Manufacturer
AARDVARK
Specifications Maximum Gallons Per Hour
300 gph
Specifications Maximum Pressure
180 psi
Specifications Maximum Speed
1750 rpm
Specifications Minimum Gallons Per Hour
100 gph
Specifications Minimum Speed
600 rpm
Specifications Motor Enclosure
Explosion Proof | Hostile Duty | IEEE 841 | Stainless Steel | TEFC | Washdown
Specifications Phase
1 | 3
Specifications Port Configuration
U
Specifications Port Type
FNPT
Specifications Power
1 hp | 1.5 hp | 1/2 hp | 3/4 hp
Specifications Seal Material
Buna | EPDM | Neoprene | Viton
Specifications Speed
1725 rpm
Specifications Suction
SAE 16 in
Specifications Voltage
110 V | 12 V | 180 V | 190 V | 200 V | 230 V | 24 V | 380 V | 460 V | 575 V | 90 V
