Aardvark AVP Rotary Vane Pump

Name: Aardvark AVP Rotary Vane Pump
Brand: AB Industrial
SKU: POS-ad0d91
Price: 899.99 USD
Availability: OutOfStock

SKU:POS-ad0d91

Powerful Aardvark AVP Rotary Vane Pump for low flow, medium pressure positive displacement. Durable construction, versatile motors & speed options.

$899.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The Aardvark AVP Rotary Vane Pump is a reliable solution for clean low flow and medium pressure positive displacement applications. With a capacity ranging from 0.1 to 11 GPM (5 to 660 GPH) at a maximum pressure of 125 psi, this pump boasts a durable construction featuring bronze or 303SS with a stainless steel shaft. It comes equipped with self-adjusting carbon vanes, bearings, and wear plates, along with a stainless steel internal bypass relief valve. The pump offers versatile motor options including AC, air, DC, or hydraulic, and can be complemented with variable speed and VFD drives for optimal performance.

Product Specifications

Specifications Coupling Type

Mag Drive

Specifications Discharge

3/8 in

Specifications Driver

AC Motor | Air Motor | DC Motor | Hydraulic Motor

Specifications Frequency

50 Hz | 60 Hz | DC Hz

Specifications Gallons Per Revolution

0.058 Gal/rev

Specifications Gph

100 gph

Specifications Housing Material

303SS | Bronze

Specifications Manufacturer

AARDVARK

Specifications Maximum Gallons Per Hour

127 gph

Specifications Maximum Pressure

180 psi

Specifications Maximum Speed

2000 rpm

Specifications Minimum Gallons Per Hour

33 gph

Specifications Minimum Speed

600 rpm

Specifications Motor Enclosure

Explosion Proof | Hostile Duty | Stainless Steel | TEFC | Washdown

Specifications Phase

1 | 3

Specifications Port Configuration

Specifications Port Type

FNPT

Specifications Power

1/2 hp | 1/3 hp

Specifications Seal Material

Buna | EPDM | Neoprene | Viton

Specifications Speed

1725 rpm

Specifications Suction

3/8 in

Specifications Voltage

110 V | 12 V | 180 V | 190 V | 200 V | 230 V | 24 V | 380 V | 460 V | 575 V | 90 V

Aardvark AVP Rotary Vane Pump
