Aardvark AVP Rotary Vane Pump

Name: Aardvark AVP Rotary Vane Pump
Brand: AB Industrial
SKU: POS-21189b
Price: 899.99 USD
Availability: OutOfStock

SKU:POS-21189b

Cost-effective Aardvark AVP Rotary Vane Pump for versatile positive displacement applications. Self-adjusting Carbon Vanes & Stainless Steel construction.

$899.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The Aardvark AVP Rotary Vane Pump is a cost-effective solution designed for clean, low flow, and medium-pressure positive displacement applications. With a capacity ranging from 0.1 to 11 GPM (5 to 660 GPH) at a maximum of 125 psi, this pump features a durable construction of Bronze or 303SS with Stainless Steel Shaft. It boasts self-adjusting Carbon Vanes, Bearings, and Wear Plates, along with a Stainless Steel Internal Bypass Relief Valve for optimal performance. The pump is equipped with Neodymium & Samarium Cobalt Magnetic Couplings, offering versatility with options for TEFC, Wash Down Duty, Stainless Steel, or Explosion Proof NEMA AC or DC Electric Motors. It can also be powered by Air or Hydraulic Motor Drives, and is compatible with Variable Speed & VFD Variable Frequency Drives for enhanced control and efficiency.

Product Specifications

Specifications Coupling Type

Mag Drive

Specifications Discharge

3/8 in

Specifications Driver

AC Motor | Air Motor | DC Motor | Hydraulic Motor

Specifications Frequency

50 Hz | 60 Hz | DC Hz

Specifications Gallons Per Revolution

0.064 Gal/rev

Specifications Gph

110 gph

Specifications Housing Material

303SS | Bronze

Specifications Manufacturer

AARDVARK

Specifications Maximum Gallons Per Hour

140 gph

Specifications Maximum Pressure

180 psi

Specifications Maximum Speed

2000 rpm

Specifications Minimum Gallons Per Hour

37 gph

Specifications Minimum Speed

600 rpm

Specifications Motor Enclosure

Explosion Proof | Hostile Duty | Stainless Steel | TEFC | Washdown

Specifications Phase

1 | 3

Specifications Port Configuration

Specifications Port Type

FNPT

Specifications Power

1/2 hp | 1/3 hp

Specifications Seal Material

Buna | EPDM | Neoprene | Viton

Specifications Speed

1725 rpm

Specifications Suction

3/8 in

Specifications Voltage

110 V | 12 V | 180 V | 190 V | 200 V | 230 V | 24 V | 380 V | 460 V | 575 V | 90 V

Aardvark AVP Rotary Vane Pump
