Aardvark AVP Rotary Vane Pump - Efficient Solution for Low Flow Applications
Aardvark AVP Rotary Vane Pump - Efficient Solution for Low Flow Applications
SKU:POS-b89382
Reliable Aardvark AVP Rotary Vane Pump for low-flow positive displacement applications. Durable construction with self-adjusting carbon vanes and stainless steel components.
Regular price
$799.99
Regular price
Sale price
$799.99
Unit price
per
Initiate Order
Aardvark AVP Rotary Vane Pump - Efficient Solution for Low Flow Applications
$799.99
Quantity: 1
Claim Your Seller Account
Aardvark AVP Rotary Vane Pump - Efficient Solution for Low Flow Applications
$799.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Aardvark AVP Rotary Vane Pump is a reliable and cost-effective solution designed for clean low-flow and medium-pressure positive displacement applications. With a durable construction featuring self-adjusting carbon vanes, bearings, and wear plates, this pump ensures consistent performance. It offers a flow rate ranging from 0.1 to 11 GPM (5 to 660 GPH) at a maximum pressure of 125 psi. The pump is versatile with options for different motor types including AC, DC, air, and hydraulic, making it suitable for various industrial settings. Additionally, its stainless steel construction and internal bypass relief valve enhance durability and operational safety.
Product Specifications
Specifications Coupling Type
Mag Drive
Specifications Discharge
0.5 in | SAE 10 in
Specifications Driver
AC Motor | Air Motor | DC Motor | Hydraulic Motor
Specifications Frequency
50 Hz | 60 Hz | DC Hz
Specifications Gallons Per Revolution
0.139 Gal/rev
Specifications Gph
240 gph
Specifications Housing Material
303SS | Bronze
Specifications Manufacturer
AARDVARK
Specifications Maximum Gallons Per Hour
305 gph
Specifications Maximum Pressure
180 psi
Specifications Maximum Speed
2000 rpm
Specifications Minimum Gallons Per Hour
80 gph
Specifications Minimum Speed
600 rpm
Specifications Motor Enclosure
Explosion Proof | Hostile Duty | IEEE 841 | Stainless Steel | TEFC | Washdown
Specifications Phase
1 | 3
Specifications Port Configuration
U
Specifications Port Type
FNPT
Specifications Power
1 hp | 1/2 hp | 1/3 hp | 3/4 hp
Specifications Seal Material
Buna | EPDM | Neoprene | Viton
Specifications Speed
1725 rpm
Specifications Suction
0.5 in | SAE 10 in
Specifications Voltage
110 V | 12 V | 180 V | 190 V | 200 V | 230 V | 24 V | 380 V | 460 V | 575 V | 90 V
