Aardvark AVP Rotary Vane Pump for Clean Low Flow & High Pressure Applications

Name: Aardvark AVP Rotary Vane Pump for Clean Low Flow & High Pressure Applications
Brand: AB Industrial
SKU: POS-48c8c7
Price: 799.99 USD
Availability: OutOfStock

SKU:POS-48c8c7

Efficient Aardvark AVP Rotary Vane Pump for clean low flow & high pressure applications. Stainless steel construction, flexible seal options, & various motor drives for industrial performance.

$799.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The Aardvark AVP Rotary Vane Pump is a reliable solution designed for clean low flow and medium to high-pressure applications. Built with self-adjusting carbon vanes, stainless steel shaft construction, and various seal options including Buna, EPDM, Neoprene, and Viton, this pump ensures efficiency and durability. With a stainless steel internal bypass relief valve, flexible port configurations, and motor drive options, it offers versatility for different operational needs. Whether powered by AC, air, DC, or hydraulic motors, this pump delivers consistent performance with a maximum pressure of 250 psi, making it ideal for industrial settings.

Product Specifications

Specifications Coupling Type

Flex

Specifications Discharge

1/2 in

Specifications Driver

AC Motor | Air Motor | DC Motor | Hydraulic Motor

Specifications Frequency

50 Hz | 60 Hz | DC Hz

Specifications Gallons Per Revolution

0.081 Gal/rev

Specifications Gph

140 gph

Specifications Housing Material

303SS | Bronze

Specifications Manufacturer

AARDVARK

Specifications Maximum Gallons Per Hour

178 gph

Specifications Maximum Pressure

250 psi

Specifications Maximum Speed

2000 rpm

Specifications Minimum Gallons Per Hour

47 gph

Specifications Minimum Speed

600 rpm

Specifications Motor Enclosure

Explosion Proof | Hostile Duty | Stainless Steel | TEFC | Washdown

Specifications Phase

1 | 3

Specifications Port Configuration

Specifications Port Type

FNPT

Specifications Power

1/2 hp | 1/3 hp | 3/4 hp

Specifications Seal Material

Buna | EPDM | Neoprene | Viton

Specifications Speed

1725 rpm

Specifications Suction

1/2 in

Specifications Voltage

110 V | 12 V | 180 V | 190 V | 200 V | 230 V | 24 V | 380 V | 460 V | 575 V | 90 V

Aardvark AVP Rotary Vane Pump for Clean Low Flow & High Pressure Applications
