Aardvark AVP Rotary Vane Pump for Clean Medium/High Pressure Applications

Name: Aardvark AVP Rotary Vane Pump for Clean Medium/High Pressure Applications
Brand: AB Industrial
SKU: POS-f3653e
Price: 799.99 USD
Availability: OutOfStock

SKU:POS-f3653e

Efficient Aardvark AVP Rotary Vane Pump for clean medium/high pressure applications, featuring durable construction and versatile motor options.

$799.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The Aardvark AVP Rotary Vane Pump is designed for clean low flow operations in medium to high pressure applications. Built with a standard modular construction, this pump features durable Bronze or 303SS with Stainless Steel Shaft for longevity. Equipped with Self Adjusting Carbon Vanes, Bearings & Wear Plates, and various sealing options including Viton, Buna, EPDM, and Neoprene, this pump ensures reliable performance. With a Stainless Steel Internal Bypass Relief Valve and Direct Drive Flex Coupling, it offers precise control and efficiency. Available with a range of AC, Air, DC, or Hydraulic Motors and Variable Speed options, this pump caters to diverse operational needs.

Product Specifications

Specifications Coupling Type

Flex

Specifications Discharge

3/8 in

Specifications Driver

AC Motor | Air Motor | DC Motor | Hydraulic Motor

Specifications Frequency

50 Hz | 60 Hz | DC Hz

Specifications Gallons Per Revolution

0.041 Gal/rev

Specifications Gph

70 gph

Specifications Housing Material

303SS | Bronze

Specifications Manufacturer

AARDVARK

Specifications Maximum Gallons Per Hour

89 gph

Specifications Maximum Pressure

250 psi

Specifications Maximum Speed

2000 rpm

Specifications Minimum Gallons Per Hour

23 gph

Specifications Minimum Speed

600 rpm

Specifications Motor Enclosure

Explosion Proof | Hostile Duty | Stainless Steel | TEFC | Washdown

Specifications Phase

1 | 3

Specifications Port Configuration

Specifications Port Type

FNPT

Specifications Power

1/2 hp | 1/3 hp

Specifications Seal Material

Buna | EPDM | Neoprene | Viton

Specifications Speed

1725 rpm

Specifications Suction

3/8 in

Specifications Voltage

110 V | 12 V | 180 V | 190 V | 200 V | 230 V | 24 V | 380 V | 460 V | 575 V | 90 V
