Aardvark AVP Rotary Vane Pump for Institutional and Consumer Use
Aardvark AVP Rotary Vane Pump for Institutional and Consumer Use
SKU:POS-0538df
High-performance Aardvark AVP Rotary Vane Pump for clean low flow applications. Durable construction with self-adjusting carbon vanes and various motor drive options.
Regular price
$1,499.99
Regular price
Sale price
$1,499.99
Unit price
per
Initiate Order
Aardvark AVP Rotary Vane Pump for Institutional and Consumer Use
$1,499.99
Quantity: 1
Claim Your Seller Account
Aardvark AVP Rotary Vane Pump for Institutional and Consumer Use
$1,499.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Aardvark AVP Rotary Vane Pump is a cost-effective solution designed for clean low flow and medium pressure positive displacement applications. With a capacity ranging from 0.1 to 11 GPM (5 to 660 GPH) at a maximum pressure of 125 psi, this pump features a durable construction with options for Bronze or 303SS housing with a Stainless Steel shaft. It is equipped with self-adjusting carbon vanes, bearings, and wear plates for long-lasting performance. The pump also includes a Stainless Steel internal bypass relief valve, Neodymium & Samarium Cobalt magnetic couplings, and is compatible with various types of electric and motor drives for enhanced flexibility and efficiency.
Product Specifications
Specifications Coupling Type
Flex
Specifications Discharge
SAE 16 in
Specifications Driver
AC Motor | Air Motor | DC Motor | Hydraulic Motor
Specifications Frequency
50 Hz | 60 Hz | DC Hz
Specifications Gallons Per Revolution
0.278 Gal/rev
Specifications Gph
480 gph
Specifications Housing Material
303SS
Specifications Manufacturer
AARDVARK
Specifications Maximum Gallons Per Hour
480 gph
Specifications Maximum Pressure
180 psi
Specifications Maximum Speed
1750 rpm
Specifications Minimum Gallons Per Hour
160 gph
Specifications Minimum Speed
600 rpm
Specifications Motor Enclosure
Explosion Proof | Hostile Duty | IEEE 841 | Stainless Steel | TEFC | Washdown
Specifications Phase
1 | 3
Specifications Port Configuration
U
Specifications Port Type
FNPT
Specifications Power
1 hp | 1.5 hp | 1/2 hp | 2 hp | 3/4 hp
Specifications Seal Material
Buna | EPDM | Neoprene | Viton
Specifications Speed
1725 rpm
Specifications Suction
SAE 16 in
Specifications Voltage
110 V | 12 V | 180 V | 190 V | 200 V | 230 V | 24 V | 380 V | 460 V | 575 V | 90 V
