Aardvark AVP Rotary Vane Pump for Medium Pressure Applications
Aardvark AVP Rotary Vane Pump for Medium Pressure Applications
SKU:POS-06a25e
Efficient Aardvark AVP Rotary Vane Pump for clean low flow & medium pressure applications.
Regular price
$699.99
Regular price
Sale price
$699.99
Unit price
per
Initiate Order
Aardvark AVP Rotary Vane Pump for Medium Pressure Applications
$699.99
Quantity: 1
Claim Your Seller Account
Aardvark AVP Rotary Vane Pump for Medium Pressure Applications
$699.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Aardvark AVP Rotary Vane Pump is a reliable solution for clean low flow and medium pressure positive displacement applications. With a standard modular construction and self-adjusting carbon vanes, this pump offers a flow rate of 0.1 to 11 GPM, ensuring efficient operation. It features bronze or 303SS construction with stainless steel shaft, a stainless steel internal bypass relief valve, and options for various motor types including AC, DC, air, and hydraulic. Ideal for institutional and government procurement needs.
Product Specifications
Specifications Coupling Type
Mag Drive
Specifications Discharge
0.5 in | SAE 10 in
Specifications Driver
AC Motor | Air Motor | DC Motor | Hydraulic Motor
Specifications Frequency
50 Hz | 60 Hz | DC Hz
Specifications Gallons Per Revolution
0.154 Gal/rev
Specifications Gph
265 gph
Specifications Housing Material
303SS | Bronze
Specifications Manufacturer
AARDVARK
Specifications Maximum Gallons Per Hour
337 gph
Specifications Maximum Pressure
180 psi
Specifications Maximum Speed
2000 rpm
Specifications Minimum Gallons Per Hour
88 gph
Specifications Minimum Speed
600 rpm
Specifications Motor Enclosure
Explosion Proof | Hostile Duty | IEEE 841 | Stainless Steel | TEFC | Washdown
Specifications Phase
1 | 3
Specifications Port Configuration
U
Specifications Port Type
FNPT
Specifications Power
1 hp | 1/2 hp | 1/3 hp | 3/4 hp
Specifications Seal Material
Buna | EPDM | Neoprene | Viton
Specifications Speed
1725 rpm
Specifications Suction
0.5 in | SAE 10 in
Specifications Voltage
110 V | 12 V | 180 V | 190 V | 200 V | 230 V | 24 V | 380 V | 460 V | 575 V | 90 V
