ABC Packaging Model 236 Top Case Sealers
ABC Packaging Model 236 Top Case Sealers
SKU:MAC-4383b3
Compact & reliable case sealers for midrange sealing requirements with non-stop case feed & quick change versatility.
Regular price
$7,599.99
Regular price
Sale price
$7,599.99
Unit price
per
Initiate Order
ABC Packaging Model 236 Top Case Sealers
$7,599.99
Quantity: 1
Claim Your Seller Account
ABC Packaging Model 236 Top Case Sealers
$7,599.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The ABC Packaging Model 236 Top Case Sealers are compact yet powerful solutions for midrange sealing needs. With non-stop case feed ensuring reliable high-speed sealing, these sealers are packed with quality production features. Built to last, they offer quick change versatility for future requirements. Featuring a steel frame construction, metering roller infeed, flap tucker, and high visibility guards, these sealers provide a secure adhesive seal. The 1 hp drive motor, automatic water eliminator, and quick changeover capabilities make them efficient and easy to maintain.
Product Specifications
Electrical Specifications Frequency
60 Hz
Electrical Specifications Industry Standards
National Electrical Manufacturers Association (NEMA 12)
Electrical Specifications Number Of Phase
3
Electrical Specifications Primary Voltage
230 V | 460 V
Models Models
236HM | 236T
Note Note
All information in this brochure was current at time of printing, however, in the continuing effort to improve the quality and construction of A-B-C equipment, we reserve the right to make changes without notice.
Quality Features Quality Features
Steel frame constructionMetering roller infeed automatically feeds cases spaced or back to backRotating flap tucker folds trailing inner flapContoured cast aluminum flap folders fold outer flapsFlexible compression rollers provide secure adhesive sealEasy access tape head for quick replenishmentClear, high visibility guards - electrically interlocked to stop the machine when openedSubstantial 1 hp drive motor powers case sealerAdjustable leveling footpads (±2")Sealed bearings minimize maintenanceAutomatic water eliminator keeps air lines dryQuick changeover with rapid-adjust hand cranks
Specifications Air Flow At 60 Pound Per Square Inch Psi Pressure
0.08 ft³/min
Specifications Applications
Case Sealers
Specifications Brand
ABC Packaging
Specifications Case Style
Center Special Slotted Container (CSSC) | Regular Slotted Case (RSC)
Specifications Mechanical Motor Power
1 hp
Specifications Speed
Up to 25 cases/min
