ABS/CNT Composite - Specific Gravity 1.04, Tensile Elongation 30%
ABS/CNT Composite - Specific Gravity 1.04, Tensile Elongation 30%
SKU:ACR-09c392
Explore our ABS/CNT Composite with specific gravity 1.04 and 30% tensile elongation for superior durability and performance.
Regular price
$39.99
Regular price
Sale price
$39.99
Unit price
per
Initiate Order
ABS/CNT Composite - Specific Gravity 1.04, Tensile Elongation 30%
$39.99
Quantity: 1
Claim Your Seller Account
ABS/CNT Composite - Specific Gravity 1.04, Tensile Elongation 30%
$39.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The ABS/CNT Composite with a specific gravity of 1.04 and a tensile elongation of 30% offers exceptional durability and versatility for a wide range of applications. This composite material is ideal for use in conductive and non-conductive environments, making it suitable for electronic parts, electrostatic spray painting, and rigid housings. Manufactured to meet ASTM standards, this composite ensures superior quality and performance, making it a reliable choice for various industrial needs.
Product Specifications
Additional Information
The products coated in conductive solution have increased adhesion, mechanical strength and abrasion resistance.MAB150 is excellent in gloss and surface quality and MAB150M is outstanding in recognition rate of laser marking.Electro-conductivity is revealed by the addition of CNT to ABSEAB120 can be processed by the non-painting and increase painting efficiency with uniform conductivityCNT is known as having excellent electrical conductivity, thermal conductivity, strength, and thermal stability. Demand for Li-ion Battery as positive electrode conductive additives has been increasing and CNT is also being used in applications such as tire treads and antistatic resins.Kumho's CNT have a highly oriented bundle structure and have been used by major battery manufacturers and tire manufacturers globally. Multiple grades of CNT are available depending on required property and each application, and we also have various types of rubber and resin compound and masterbatches.Kumho Petrochemical with one of the world's largest synthetic rubber manufacturing capacities was established in 1970 and developing their business in several fields including synthetic resins, specialty chemicals, nanocarbons, energy, and building materials.Major application with Kumho's CNTLi-ion Battery as positive electrode conductive additives for automotiveTire treadsElectronic Parts TraysConductive coatingElectro-Magnetic Interference (EMI) Shielding CompositeConductive resin/rubber
Applications
Pipes | Sheets | Thermoformed Trays
Technical Specs Brands
Heidon
Properties Flexural Modulus 10 Millimeter Mm Per Minute
14,000 kgf/cm²
Properties Flexural Strength 10 Millimeter Mm Per Minute
320 kgf/cm²
Properties Heat Deflection Temperature 186 Kilogram Kgsq
85 ºC
Properties Izod Impact Notched 32 Millimeter Mm
5 kgf·cm/cm
Properties Melt Flow Index 200 Degree Celsius C Temperat
30 g/10min
Properties Rockwell Hardness R Scale
81
Properties Specific Gravity
1.04
Properties Tensile Elongation At Break 50 Millimeter Mm
30 %
Properties Tensile Strength 50 Millimeter Mm Per Minute
245 kgf/cm²
Properties Test Method For Flexural Modulus 10 Millimete
American Society for Testing and Materials (ASTM) D256
Properties Test Method For Flexural Strength 10 Millimet
American Society for Testing and Materials (ASTM) D790
Properties Test Method For Heat Deflection Temperature 1
American Society for Testing and Materials (ASTM) D648
Properties Test Method For Izod Impact Notched 32 Millim
American Society for Testing and Materials (ASTM) D256
Properties Test Method For Melt Flow Index 200 Degree Ce
American Society for Testing and Materials (ASTM) D1238
Properties Test Method For Rockwell Hardness R Scale
American Society for Testing and Materials (ASTM) D785
Properties Test Method For Specific Gravity
American Society for Testing and Materials (ASTM) D792
Properties Test Method For Surface Resistivity At 23 Deg
American Society for Testing and Materials (ASTM) D257
Properties Test Method For Tensile Elongation At Break 5
American Society for Testing and Materials (ASTM) D638
Properties Test Method For Tensile Strength 50 Millimete
American Society for Testing and Materials (ASTM) D638
