ACCU-CAL™ 50 UV Radiometer for Industrial UV Curing Systems
ACCU-CAL™ 50 UV Radiometer for Industrial UV Curing Systems
SKU:ULT-371611
Accurate UV intensity measurement for industrial curing processes. Spectral sensitivity 320-395 nm, range 1mW/cm² - 40 W/cm².
Regular price
$2,499.99
Regular price
Sale price
$2,499.99
Unit price
per
Initiate Order
ACCU-CAL™ 50 UV Radiometer for Industrial UV Curing Systems
$2,499.99
Quantity: 1
Claim Your Seller Account
ACCU-CAL™ 50 UV Radiometer for Industrial UV Curing Systems
$2,499.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The ACCU-CAL™ 50 UV Radiometer is a reliable tool for monitoring UV light intensity in industrial UV curing systems, ensuring consistent curing processes. With a spectral sensitivity ranging from 320 to 395 nm (UVA), this radiometer accurately measures intensities from 1 mW/cm² to 40 W/cm². Designed for use with lightguides, UV flood systems, and conveyors, it allows for precise UV light measurements. The instrument features a user-friendly interface, robust construction, and PTB and NIST traceability, making it a valuable asset for quality control in light-curing applications.
Product Specifications
Dymax Accu Cal Radiometers 0
Dymax® offers ACCU-CAL⢠radiometers for spots, floods, and conveyors. Kits for spot lamps include the complete radiometer with 3, 5, and 8 mm lightguide adapters and a lightguide simulator. Adapter kits are available separately for users who have an existing flood/conveyor kit and need to use it for spot systems. All radiometer kits include a storage/carrying case. ACCU-CAL⢠radiometers are calibrated to measure either UV-A (320 to 390 nm), LED (~ 350 to 450 nm), or visible (395 nm to 465 nm) light intensity.
Features 0
Simple to OperateCan be Used to Test Spot or Flood Lamps, as Well as Conveyor SystemsSet Screw Locks Lightguide in PlacePTB and NIST Traceable
Measurement Modes Dose Measurement Modes
J/cm²
Measurement Modes Intensity Measurement Modes
mW/cm² | W/cm²
Measurement Modes Peak Intensity Measurement Modes
mW/cm² | W/cm²
Meter Dimensions Meter Length
120 mm
Meter Dimensions Meter Thickness
23 mm
Meter Dimensions Meter Width
65 mm
Operating Temperature Ranges Continuous Detector Operating Tempe
120 ºC
Operating Temperature Ranges Continuous Peak Operating Temperatu
200 ºC
Operating Temperature Ranges Optometer Operating Temperature Ran
+ 5 to + 40 ºC
Power Supply Battery Type
AA
Power Supply Number Of Battery
2
Radiometer Calibration 0
Dymax® recommends calibrating the ACCU-CAL⢠50 radiometer annually to ensure proper operation of the instrument. Calibration services are available through Dymax®.
Resolution Dose
1 mJ/cm²
Resolution Intensity
1 mW/cm²
Sensor Dimensions Cable Length
1 m
Sensor Dimensions Diameter
37 mm
Sensor Dimensions Photo Sensor Diameter
9 mm
Sensor Dimensions Thickness
8 mm
Specifications Approval
CE Marked
Specifications Battery Life
250 h
Specifications Calibration Period
12 months
Specifications Intensity Range
1 mW/cm² to 40 W/cm²
Specifications Light Sources Application
Conveyors | Floods
Specifications Spectral Sensitivity
320 to 395 nm
Three Reasons To Use A Ultraviolet Uvvisible Radiometer Three Re
Maintaining a Light-Curing Process - A radiometer measures whether a light-curing system is providing intensity above the "bulb change" intensity. Radiometers provide the same monitoring control for light curing processes that thermometers provide for thermal processes.Providing a Worker Friendly Light-Curing Process - The ACCU-CAL⢠50 is sufficiently sensitive to measure the intensity of stray or reflected UV light (as little as 1 mW/cm2). Dymax® recommends that worker UVA exposure not exceed 1 mW/cm2. For reference, UV (320 to 395 nm) intensity on a sunny day can range from 2 to 6 mW/cm2.Measuring Transmission Rates Through Substrates - A radiometer can be used to measure the transmission rates of various wavelengths through substrates that absorb UV and/or visible light. To assure an effective curing process it is critical to measure the light intensity reaching the resin below the intervening substrate.
