Accu-Clamp Precision Sleeve Square Bore Couplings
Accu-Clamp Precision Sleeve Square Bore Couplings
SKU:ROU-3861f6
Achieve precise shaft alignment with our Accu-Clamp Precision Sleeve Couplings. Easy assembly, high clamping power & shaft protection. Steel, Stainless Steel, Aluminum options.
Regular price
$49.99
Regular price
Sale price
$49.99
Unit price
per
Initiate Order
Accu-Clamp Precision Sleeve Square Bore Couplings
$49.99
Quantity: 1
Claim Your Seller Account
Accu-Clamp Precision Sleeve Square Bore Couplings
$49.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Enhance shaft alignment with our Accu-Clamp Precision Sleeve Square Bore Couplings. Designed with a balanced two-piece split construction, this coupling ensures axial runout less than .001" TIR. The exclusive solid center section offers a close tolerance fit on ground shafting, incorporating self-centering clamping collars for precise assembly and adjustment. With a smooth bore to protect shafts and options in Steel, Stainless Steel, and Aluminum, these couplings provide high clamping power and ease of use.
Product Specifications
Dimensional Attributes Bore Size A
7/16 in
Dimensional Attributes Bore Size B
7/16 in
Dimensional Attributes Outside Diameter
1.500 in
Dimensional Attributes Recessed Screw
Yes
Dimensional Attributes Screw Material
Alloy Steel
Dimensional Attributes Screw Size
10-32 x 5/8
Dimensional Attributes Total Length
2.250 in
Specifications Alloy
1215
Specifications Approximate Weight
0.82 lb
Specifications Country Of Origin
USA
Specifications Finish
Black Oxide
Specifications Material
Steel
Specifications Part Number
15L007007PSC
Specifications Reach Compliant
Yes
Specifications Rohs2 Compliant
Yes
Specifications Series
Signature
Specifications Type
Precision Sleeve
Specifications Upc Code
662786040283
