Acrolab Angle Industrial Thermocouples
Acrolab Angle Industrial Thermocouples
SKU:THE-be5a38
Acrolab Angle Industrial Thermocouples for precise industrial temperature measurement.
Regular price
$129.99
Regular price
Sale price
$129.99
Unit price
per
Initiate Order
Acrolab Angle Industrial Thermocouples
$129.99
Quantity: 1
Claim Your Seller Account
Acrolab Angle Industrial Thermocouples
$129.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Acrolab Angle Industrial Thermocouples with Metal Protection Tubes are expertly designed for over-the-side temperature measurement in industrial settings. These thermocouples offer a range of protection tube materials and thermocouple calibrations, including J, K, R, and S types. With options such as dual or single junction styles, various mounting choices, and terminations, this product ensures precise and reliable temperature readings. Ideal for meeting the stringent demands of industrial applications.
Product Specifications
Schedule 40 Pipe Alloy And Size
Code - 5-50Material - 446 Stainless SteelInside Diameter - 0.622 in.Outside Diameter - 0.840 in.Thread Size - 1/2 in.Thread Type- National Pipe Thread (NPT)Code - 5-75Material - 446 Stainless SteelInside Diameter - 0.824 in.Outside Diameter - 1.050 in.Thread Size - 3/4 in.Thread Type- National Pipe Thread (NPT)Code - 6-25Material - Carbon SteelInside Diameter - 0.364 in.Outside Diameter - 0.540 in.Thread Size - 1/2 in.Thread Type- National Pipe Thread (NPT)Code - 6-50Material - Carbon SteelInside Diameter - 0.622 in.Outside Diameter - 0.840 in.Thread Size - 1/2 in.Thread Type- National Pipe Thread (NPT)Code - 6-75Material - Carbon SteelInside Diameter - 0.824 in.Outside Diameter - 1.050 in.Thread Size - 3/4 in.Thread Type- National Pipe Thread (NPT)Code - 6-100Material - Carbon SteelInside Diameter - 1.049 in.Outside Diameter - 1.315 in.Thread Size - 1 in.Thread Type- National Pipe Thread (NPT)Code - 7-50Material - Inconel 601Inside Diameter - 0.622 in.Outside Diameter - 0.840 in.Thread Size - 1/2 in.Thread Type- National Pipe Thread (NPT)Code - 7-75Material - Inconel 601Inside Diameter - 0.824 in.Outside Diameter - 1.050 in.Thread Size - 3/4 in.Thread Type- National Pipe Thread (NPT)Code - 7-100Material - Inconel 601Inside Diameter - 1.049 in.Outside Diameter - 1.315 in.Thread Size - 1 in.Thread Type- National Pipe Thread (NPT)Code - 8-25Material - 316 Stainless Steel Inside Diameter - 0.364 in.Outside Diameter - 0.840 in.Thread Size - 1/2 in.Thread Type- National Pipe Thread (NPT)Code - 8-50Material - 316 Stainless Steel Inside Diameter - 0.622 in.Outside Diameter - 1.050 in.Thread Size - 1/2 in.Thread Type- National Pipe Thread (NPT)Code - 8-75Material - 316 Stainless Steel Inside Diameter - 0.824 in.Outside Diameter - 1.050 in.Thread Size - 3/4 in.Thread Type- National Pipe Thread (NPT)Code - 11-75Material - Cast IronInside Diameter - 1.049 in.Outside Diameter - 0.840 in.Thread Size - 1 in.Thread Type- National Pipe Thread (NPT)Code - 12-75Material - LT-1 Metal CeramicInside Diameter - 0.625 in.Outside Diameter - 1.625 in.Thread Size - 3/4 in.Thread Type- National Pipe Thread (NPT)Code - 13-75Material - Silicone NitrideInside Diameter - 0.625 in.Outside Diameter - 1.125 in.Thread Size - 3/4 in.Thread Type- National Pipe Thread (NPT)Code - 14-75Material - Refractory CoatedInside Diameter - 0.493 in.Outside Diameter - 1.500 in.Thread Size - 3/4 in.Thread Type- National Pipe Thread (NPT)Code - 15-75Material - HexoloyInside Diameter - 0.500 in.Outside Diameter - 0.750 in.Thread Size - 3/4 in.Thread Type- National Pipe Thread (NPT)Code - 16-75Material - VesuviusInside Diameter - 0.824 in.Outside Diameter - 2.000 in.Thread Size - 3/4 in.Thread Type- National Pipe Thread (NPT)
Specifications Calibration Type
J - Iron/Constantan | K - Chromel/Alumel | R - Platinum Rhodium/Platinum | S - Platinum Rhodium/Platinum
Specifications Cold Length
Specify
Specifications Hot Length
Specify
Specifications Junction Styles
Dual | Single
Specifications Note For Cold Length
Actual Length Provided is 2.5" Longer than Specified to Allow for Terminal Connections.
Specifications Options
A - Open End (Closed End Standard) | AA - Special Construction | B - Internal Ground Screw in Head | C(X) - 1/2" NPT Welded Steel Bushing (0.25" Size Pipe Only) | D(X) - 3/4" NPT Welded Steel Bushing (0.50" Size Pipe Only) | E(X) - 1" NPT Welded Steel Bushing (0.50", 0.75" Size Pipe Only) | F(X) - 1-1/8" NPT Welded Steel Bushing (0.50", 0.75", 1" Size Pipe Only) | G(X) - 1-1/2" NPT Welded Steel Bushing (0.50", 0.75", 1" Size Pipe Only) | H - Adjustable Steel Flange | K - Cast Aluminum Weatherproof Head | L - Thermocouple Insulated from Tube | M - Special Limits of Error | P - Steel Union and Nipples to Connect Head to Protection Tube | SS - Stainless Steel Bushing | V - SS Union and Nipples to Connect Head to Protection Tube | W - Protective White Epoxy Coating on Head | X - CSA Approved Explosion Proof Head
