Acrolab HBA-MI Mineral Insulated Band Heater
Acrolab HBA-MI Mineral Insulated Band Heater
SKU:HEA-076828
Acrolab HBA-MI Band Heater: High-performance heating solution certified to ISO 9001:2015.
Regular price
$59.99
Regular price
Sale price
$59.99
Unit price
per
Initiate Order
Acrolab HBA-MI Mineral Insulated Band Heater
$59.99
Quantity: 1
Claim Your Seller Account
Acrolab HBA-MI Mineral Insulated Band Heater
$59.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Acrolab HBA-MI Mineral Insulated Band Heater offers superior performance with high wattage capabilities, ideal for industrial applications requiring precise and efficient heating. Crafted with premium materials, this band heater ensures reliable and consistent temperature control, surpassing standard mica heaters. Customize it to meet your specific requirements for diameter, width, voltage, wattage, lead type, and more. Certified by ISO 9001:2015, this heater meets stringent quality standards for institutional and government procurement needs.
Product Specifications
Specifications Certifications
International Organization for Standardization (ISO 9001: 2015)
Specifications Clamping Styles
BN - Barrel Nuts | CP - Clamping Pads | FL - Flange Lock-Up | IS - Independent Strap | LP - Low Profile Barrel Nuts | LT - Latch and Trunnion | SB - Spring Loaded Barrel Nuts | WL - Wedge Lock
Specifications Construction Options
2P - 2 Piece Construction (Note: wattage indicated in box 5 will be total wattage) | H - Hole (Indicate inside diameter / location) | TC - Built In Thermocouple
Specifications Inside Diameter
Specify
Specifications Lead Length
Specify
Specifications Lead Type
FG - Fiberglass (482ºF) | FGA - Fiberglass with Armor (482ºF) | FGS - Fiberglass with Stainless Steel Braid (482ºF) | HFG - Hi-Temp Fiberglass (932ºF) | HFGA - Hi-Temp Fiberglass with Armor (932ºF) | HFGS - Hi-Temp Fiberglass with Stainless Steel Braid (932ºF) | T - Polytetrafluoroethylene (PTFE) (500ºF) | TA - Polytetrafluoroethylene (PTFE) with Armor (500ºF) | TB - Terminal Box
Specifications Lead Wire Terminations
C - Exit Either Side of the Gap on Thickness | C1- 90º Exit with Cap and Tube Near Gap, Exiting Towards Opening | C2 - 90º Cap with Tube Near Gap, Tangential | C3 - 45º Exit with Cap and Tube Near Gap, Exiting Towards Opening | C5 - 90º Exit with Cap and Tube Opposite Gap, Exiting Towards Opening | C6 - 90º Cap with Tube Opposite Gap, Tangential | C7 - 45º Exit with Cap and Tube Opposite Gap, Exiting Towards Opening | D - Leads Exiting Opposite Gap | E - Leads Exit Near Gap | F - Leads Exiting either Side of the Gap | I - Leads Exiting Opposite on Thickness
Specifications Plug Terminations
K00 - European Plug Vertical with Box | K3P - European Plug 3 Prong with Ground | K45 - European Plug 45º with Box | K90 - European Plug Tangential with Box
Specifications Screw Terminal Terminations
A - Separate on Opposite Sides of the Gap | AV - Separate on Opposite Sides of the Gap with Ceramic Protective Covers | B1 - Along the Width Side by Side | B1G - Along the Width Side by Side with Protective Terminal Box | B1V - Along the Width Side by Side with Ceramic Protective Covers | B2 - Along the Length Side by Side | B2G - Along the Length Side by Side with Protective Terminal Box | B2V - Along the Length Side by Side with Ceramic Protective Covers
Specifications Style
HBA-MI Mineral Insulated Band Heater
Specifications Voltage
120 V | 240 V | 480 V | Other
Specifications Wattage
Specify
Specifications Width
Specify
