Acrolab HCE Ceramic Band Heaters
Acrolab HCE Ceramic Band Heaters
SKU:HEA-93d656
Customizable Ceramic Band Heaters for high-temp applications. ISO 9001:2015 certified.
Regular price
$99.99
Regular price
Sale price
$99.99
Unit price
per
Initiate Order
Acrolab HCE Ceramic Band Heaters
$99.99
Quantity: 1
Claim Your Seller Account
Acrolab HCE Ceramic Band Heaters
$99.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Acrolab HCE Ceramic Band Heaters are engineered for high-temperature applications, offering precise heating solutions. With customizable options including inside diameter, width, voltage, wattage, lead configurations, and terminal terminations, these band heaters provide unparalleled flexibility and efficiency. Certified by ISO 9001:2015, ensuring quality manufacturing standards for institutional and industrial use.
Product Specifications
Specifications Certifications
International Organization for Standardization (ISO 9001: 2015)
Specifications Clamping Styles
BN - Barrel Nuts | FL - Flange Lock-Up | LT - Latch and Trunnion
Specifications Construction Options
2P - 2 Piece Construction (Note: wattage indicated in box 5 will be total wattage) | H - Hole (Indicate inside diameter / location) | TC - Built In Thermocouple
Specifications Inside Diameter
Specify
Specifications Lead Length
Specify
Specifications Lead Type
FG - Fiberglass (482ºF) | FGA - Fiberglass with Armor (482ºF) | FGS - Fiberglass with Stainless Steel Braid (482ºF) | HFG - Hi-Temp Fiberglass (932ºF) | HFGA - Hi-Temp Fiberglass with Armor (932ºF) | HFGS - Hi-Temp Fiberglass with Stainless Steel Braid (932ºF) | TB - Terminal Box
Specifications Lead Wire Terminations
E - Leads Exit Near Gap
Specifications Plug Terminations
K00 - European Plug Vertical with Box | K90 - European Plug Tangential with Box
Specifications Screw Terminal Terminations
A - Separate on Opposite Sides of the Gap | AV - Separate on Opposite Sides of the Gap with Ceramic Protective Covers | B1 - Along the Width Side by Side | B1G - Along the Width Side by Side with Protective Terminal Box | B1V - Along the Width Side by Side with Ceramic Protective Covers | B2 - Along the Length Side by Side | B2G - Along the Length Side by Side with Protective Terminal Box | B2V - Along the Length Side by Side with Ceramic Protective Covers
Specifications Style
HCE Ceramic Band Heater
Specifications Voltage
120 V | 240 V | 480 V | Other
Specifications Wattage
Specify
Specifications Width
Specify
