Adjustable Thrust Collar Assembly - Stainless Steel
Adjustable Thrust Collar Assembly - Stainless Steel
SKU:ROU-939296
Achieve precise axial adjustability with the Stainless Steel Adjustable Thrust Collar Assembly. Ideal for heavy part movement and precise positioning.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
Adjustable Thrust Collar Assembly - Stainless Steel
$29.99
Quantity: 1
Claim Your Seller Account
Adjustable Thrust Collar Assembly - Stainless Steel
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Adjustable Thrust Collar Assembly in stainless steel offers bi-directional axial adjustability along a shaft, ideal for precise positioning and movement of heavy parts. With knurled edges for easy turning and superior axial holding power, this assembly consists of two one-piece collars with a male-female connecting hub, allowing infinite controlled movement. It provides 3/8" to 3/4" axial adjustability, perfect for applications like pre-loading bearings. Made in the USA with a sleek finish and RoHS2 compliant, this assembly is durable, reliable, and easy to adjust, ensuring efficiency in various industrial settings.
Product Specifications
Dimensional Attributes Adjustment Range
0.375 in
Dimensional Attributes Bore Size
3/8 in
Dimensional Attributes Closed Width
1.500 in
Dimensional Attributes Distance Across Flats
0.750 in
Dimensional Attributes Outside Diameter
0.875 in
Dimensional Attributes Recessed Screw
Yes
Dimensional Attributes Screw Material
18-8 Stainless Steel
Dimensional Attributes Screw Size
6-32 x 3/8
Dimensional Attributes Total Width
1.875 in
Specifications Alloy
303
Specifications Approximate Weight
0.16 lb
Specifications Country Of Origin
USA
Specifications Finish
None
Specifications Material
Stainless Steel
Specifications Part Number
ATCS006
Specifications Reach Compliant
Yes
Specifications Rohs2 Compliant
Yes
Specifications Series
Solution
Specifications Upc Code
662786023132
