Advanced Oxygen Monitor with Remote Sensor
Advanced Oxygen Monitor with Remote Sensor
SKU:OXY-96c539
Cutting-edge Oxygen Monitor with Remote Sensor for precise oxygen level monitoring in various environments.
Regular price
$289.99
Regular price
Sale price
$289.99
Unit price
per
Initiate Order
Advanced Oxygen Monitor with Remote Sensor
$289.99
Quantity: 1
Claim Your Seller Account
Advanced Oxygen Monitor with Remote Sensor
$289.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Advanced Oxygen Monitor with Remote Sensor is a top-of-the-line solution for monitoring oxygen levels in various environments. This specialized monitor features a remote sensor capability, allowing it to be positioned up to 10 feet away from the main unit. Ideal for use in freezers or unmanned areas, the remote sensor ensures accurate readings while maintaining a safe distance. With a digital display and analog output range of 4 to 20 mA, this monitor offers precise measurements of oxygen levels ranging from 0 to 25%. Additionally, it operates reliably in extreme temperatures from -40 to +55 ºC and features dual-level alarm relay contacts for enhanced safety. The long-lasting zirconium oxide sensor cell provides dependable performance, while the polycarbonate enclosure ensures durability. Perfect for industrial, laboratory, and commercial settings, this monitor requires no calibration adjustments and comes with a 3-year warranty.
Product Specifications
Options Options
24 VDC Power Supply (P/N 45101)Horn and Strobe Combo (P/N 42002)Remote Display (P/N 99091)
Specifications Accuracy
± 1 % of Full Scale
Specifications Current
250 mA
Specifications Depth
3.25 in | 82.5 mm
Specifications Digital Display Analog Output Range
4 to 20 mA
Specifications Direct Current Dc Voltage
24 V
Specifications Display
Long life zirconium oxide sensor cell.
Specifications Enclosure Material
Polycarbonate
Specifications Gases Detected
Oxygen (O2)
Specifications Height
4.5 in | 114.3 mm
Specifications Operating Temperature
-40 to +55 ºC
Specifications Oxygen Range
0 to 25 %
Specifications Required Calibration
No Zero or Span Pot Adjustment Required
Specifications Sampling Method
Diffusion
Specifications Sensor Life
10+ years under normal conditions
Specifications Signal Outputs
4-20 mA Analog Output Dual Level Alarm Relay Contacts
Specifications Weight
1.6 lb | 0.8 kg
Specifications Width
6.5 in | 165.1 mm
Standard Features 0
10 + Years No Calibration SensorTwo-Alarm Relays for 19.5% and 18.0%No Maintenance RequiredUltra Loud Built-in audible alarm 90 DBRemote sensor capability up to 10 feet3 Year WarrantyOperates in Freezers at-40 ºCNo Drift due to Thunderstorms or barometric pressure changesWall mounting bracketsCE and UL approved
