Advanced Plate Stripping Evaporator
Advanced Plate Stripping Evaporator
SKU:EVA-6f0862
Cutting-edge Plate Evaporator with superior efficiency and customizable design for various industrial applications.
Regular price
$18,999.00
Regular price
Sale price
$18,999.00
Unit price
per
Initiate Order
Advanced Plate Stripping Evaporator
$18,999.00
Quantity: 1
Claim Your Seller Account
Advanced Plate Stripping Evaporator
$18,999.00
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Advanced Plate Stripping Evaporator by Thermal Kinetics offers cutting-edge plate evaporation technology designed for a wide range of applications in industries such as Agricultural Chemical Production, Food and Beverage, Pharmaceutical Production, and more. With features like low hold-up, foaming and fouling control, and the ability to install in low head room areas, this system can be customized to meet the specific requirements of high velocity shearing or fully suppressed boiling evaporator processes. The use of framed plates as the heating surface allows for easy maintenance, inspection, and adjustment of the evaporation rate, ensuring optimal performance and efficiency.
Product Specifications
Additional Information Additional Information
Instead of tube and shell heat exchangers, framed plates are used as the heating surface. The plate unit can be employed as a wide gap style, a narrow gap for high shear, or a customized plate evaporator from available suppliers. In these units a product plate and a steam plate are connected alternately.Since the plate package can be opened easily, surfaces can be inspected, individual plates can be changed if necessary, and the evaporation rate can be altered by adding or removing individual plates.
Applications Applications
Brewery Waste Concentration Systems | Cannabinoid Oil Refining | Chemical Plant Waste Systems | Chemical Recovery In Metal Plating processes | Concentration Of Sugar Solutions | Evaporative Crystallizers For Salts | Gelatin Production | Pharmaceutical Product Recovery From Waste Streams | Phosphoric Acid Production | Removal Of Solvents From Oils | Sodium Hydroxide (NaOH) Production | Sulfuric Acid Production
Components Components
Condenser | Heat Recovery Exchangers | Main Evaporator Heater | Vacuum System | Vapor/Liquid Separator
Industries Industries
Agricultural Chemical Production | Chemical Production | Food and Beverage | Fuel Ethanol | Oil and Gas | Pharmaceutical Production | Pulp and Paper
Key Benefits Key Benefits
Low hold-up, easy cleaningGood foaming and fouling controlInstalls in low head room areasCan be designed as a high velocity shearing evaporator or fully suppressed boiling evaporator depending on the application.
