AISI 304 Stainless Steel (18-8) Flat Phillips® Drive Machine Screw

Name: AISI 304 Stainless Steel (18-8) Flat Phillips® Drive Machine Screw
Brand: Aspen Fasteners
SKU: SCR-c7faad
Price: 49.99 USD
Availability: OutOfStock

SKU:SCR-c7faad

N/A

$49.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

A fully threaded screw with unified machine thread and a blunt point. Usually used with a mating nut or driven into a pre-tapped hole. A large variety of head styles paired with numerous drives types allow for virtually unlimited uses.

Product Specifications

Additional Information

Machine screws are designed for applications with a pre-tapped hole or mated to a threaded nut.Flat countersunk head screws sit flush with the surface of the material they are inserted into.Type 304 stainless steel is defined as a Chromium-Nickel austenitic alloy.Stainless steel significantly improves resistance to tarnishing or corrosion.

Specifications Coating

Uncoated

Specifications Drive Detail

Phillips® Type H

Specifications Drive Style

Cruciform Recess Drive

Specifications Head Detail

82 Degree Countersink

Specifications Head Style

Flat Countersunk Head

Specifications Industry Standards And Specifications

American Society of Mechanical Engineers (ASME B18.6.3)

Specifications Material

Stainless Steel

Specifications Material Grade

American Iron and Steel Institute (AISI) 304 Stainless Steel (18-8)

Specifications System Of Measurement

Inch

Specifications Thread Direction

Right-Hand Thread

Specifications Thread Length

Full Thread

AISI 304 Stainless Steel (18-8) Flat Phillips® Drive Machine Screw
