Alliance Sensors Group Linear Potentiometer Replacement Sensor - 45mm OD, 6in Stroke, 4-20mA Output

Name: Alliance Sensors Group Linear Potentiometer Replacement Sensor - 45mm OD, 6in Stroke, 4-20mA Output
Brand: Alliance Sensors Group
SKU: LIN-ea084b
Price: 79.99 USD
Availability: OutOfStock

SKU:LIN-ea084b

Enhance your system with the precision of Alliance Sensors Group Linear Potentiometer Replacement Sensor - 45mm OD, 6in Stroke

$79.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

Upgrade your linear potentiometer system with the Alliance Sensors Group Linear Potentiometer Replacement Sensor. With a 45mm Outside Diameter, 6in Stroke, and 4-20mA Output Current, this stainless steel sensor ensures high accuracy (<0.25% Linearity) and durability. It operates in a wide temperature range (-40 to 105 ºC) with a fast update rate of 300 Hz. Approved for European Conformity (CE), this sensor guarantees reliable performance and seamless integration.

Product Specifications

Technical Specs Brands

Alliance Sensors Group

Technical Specs Connector Type

Radial M12

Technical Specs European Conformity Ce Approved

Yes

Technical Specs Linearity

<0.25 % of Full Scale

Technical Specs Material

Stainless Steel Body

Technical Specs Output Current

4 to 20 mA

Technical Specs Outside Diameter

45 mm

Technical Specs Range

6 in

Technical Specs Resolution

0.025 % of Full Scale

Technical Specs Stroke

6 in

Technical Specs Temperature Range

-40 to 105 ºC

Technical Specs Type

Rod Ends

Technical Specs Update Rate

300 Hz

Alliance Sensors Group Linear Potentiometer Replacement Sensor - 45mm OD, 6in Stroke, 4-20mA Output
