Alloy C22 Sch. 5 Seamless/Welded Pipe - 6 Inch OD
Alloy C22 Sch. 5 Seamless/Welded Pipe - 6 Inch OD
SKU:NIC-518ce0
Highly ductile Alloy C22 Pipe with excellent corrosion resistance. Available in 6" OD, meeting ASME/ASTM standards.
Regular price
$299.99
Regular price
Sale price
$299.99
Unit price
per
Initiate Order
Alloy C22 Sch. 5 Seamless/Welded Pipe - 6 Inch OD
$299.99
Quantity: 1
Claim Your Seller Account
Alloy C22 Sch. 5 Seamless/Welded Pipe - 6 Inch OD
$299.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Alloy C22 Pipe offers exceptional corrosion resistance in austenitic nickel-based superalloy construction. Also known as Inconel® 22 and Hastelloy® C22, this pipe is highly ductile, facilitating easy cold forming processes. Suitable for diverse industries, it resists corrosion, pitting, crevice corrosion, and stress corrosion cracking. With specifications meeting ASME and ASTM standards, this pipe is available in sizes ranging from 1/8" to 26", catering to various industrial needs.
Product Specifications
Additional Information Additional Information
Common applications include chemical processing, paper and pulp, oil and gas, pesticide production, sour gas services, and waste incinerators. Providing considerable resistance at elevated temperatures, Inconel® 22 has been adopted for nuclear fuel reprocessing, flue gas desulfurization and seawater-based applications.With the nickel as its primary base, Inconel® 22 alloy includes a chemical composition of 20-22.5% Cr, 12.5-14.5% Mo, a maximum of 2.5% Co, 2.5-3.5% W, and 2-6% Fe. For annealing treatment, temperature ranges should remain between 2020 and 2150 ºF. Inconel® 22 is suited for applications that require superior performance at elevated temperatures and for its full spectrum of anti-corrosion characteristics.
Nickel Alloy Compositions Alloy
Alloy C22
Nickel Alloy Compositions Astm Specification
ASME Code Case 2226 | ASME Code Case N-621 | ASME SB 619/SB 775 | ASME SB 622/SB 829 | ASME SB 626/SB 751 | ASTM B 619/B 775 | ASTM B 622/B 829 | ASTM B 626/B 751 | DIN 17751 | ISO 6207
Nickel Alloy Compositions Density
8.69 g/cm³ | 0.314 lbs/in³
Specifications Material
Hastelloy®
Specifications Nominal Diameter Metric
150 mm
Specifications Nominal Diameter Standard
6 inches
Specifications Od
6.625 inches | 168.275 mm
Specifications Shapeform
Pipe
Specifications Thickness
Sch. 5
