Aluminum Alloy Rod 3.18mm Diameter Al98.8/Mg0.7/Si0.5
Aluminum Alloy Rod 3.18mm Diameter Al98.8/Mg0.7/Si0.5
SKU:ALU-4fcb44
High-performance 3.18mm Aluminum Alloy Rod for industrial applications.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
Aluminum Alloy Rod 3.18mm Diameter Al98.8/Mg0.7/Si0.5
$29.99
Quantity: 1
Claim Your Seller Account
Aluminum Alloy Rod 3.18mm Diameter Al98.8/Mg0.7/Si0.5
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Meet your industrial needs with our Aluminum Alloy Rod. This straight 3.18mm diameter rod, crafted from Al98.8/Mg0.7/Si0.5, offers superior mechanical properties. Enjoy a tensile strength of 150.00 to 250.00 MPa, hardness of 35 to 75 Brinell, and thermal conductivity of 190.00 to 205.00 W m-1K-1. Compliant with Federal procurement standards, this rod ensures quality and performance.
Product Specifications
Electrical Properties Electrical Resistivity
3.25 to 3.50 µΩ·cm
Electrical Properties Temperature Coefficient
0.00300 to 0.00360 k-1
Material Material
Aluminum/Magnesium/SiliconAlloys are mixtures of a metal with other elements, the precise combination being governed by the required properties. Alloys are generally considered to be metallic in nature i.e. they have good thermal and electrical conductivities).Alloys can be manufactured by various routes, the most widely used being to melt the constituents together and to cool the resultant mixture to form a single or multi-phase solid.
Mechanical Properties Elongation At Break
< 30.0 %
Mechanical Properties Hardness Brinell
35 to 75
Mechanical Properties Izod Impact Strength
30.0 to 45.0 J m-1
Mechanical Properties Modulus Of Elasticity
71.0 GPa
Mechanical Properties Shear Strength
100 to 160 MPa
Mechanical Properties Tensile Strength
150.00 to 250.00 MPa
Physical Properties Density
2.700 g·cm-3
Specifications Diameter
3.18 mm
Specifications Form
Rod
Specifications Length
100 to 1000 mm
Specifications Temper
Soft
Thermal Properties Coefficient Of Thermal Expansion At 20 To 100
23.000 x10-6 K-1
Thermal Properties Thermal Conductivity At 23 Degree Celsius C T
190.00 to 205.00 W m-1K-1
Tolerances Tolerance For 100 Millimeter Mm Length Round
-1 % | +5 %
Tolerances Tolerance For 10 Millimeter Mm Diameter
5 %
Tolerances Tolerance For 10 Millimeter Mm Diameter
10 %
Type Type
AlloyAlloys are mixtures of a metal with other elements, the precise combination being governed by the required properties. Alloys are generally considered to be metallic in nature i.e. they have good thermal and electrical conductivities). Alloys can be manufactured by various routes, the most widely used being to melt the constituents together and to cool the resultant mixture to form a single or multi-phase solid.
Analysis Copper Cu
<1000 ppm
Analysis Iron Fe
<4000 ppm
