Aluminum Alloy TPR 51.0mm Self-Piercing Rivet
Aluminum Alloy TPR 51.0mm Self-Piercing Rivet
SKU:TPR-5b6d88
Durable aluminum alloy self-piercing rivet with 51.0mm body length, ideal for various applications.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
Aluminum Alloy TPR 51.0mm Self-Piercing Rivet
$29.99
Quantity: 1
Claim Your Seller Account
Aluminum Alloy TPR 51.0mm Self-Piercing Rivet
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Aluminum Alloy TPR 51.0mm Self-Piercing Rivet is a durable and versatile fastening solution suitable for a wide range of applications. With a body length of 51.0mm and a grip range from 18.0mm to 32.0mm, it offers reliable shear and tensile forces of 250kgf and 320kgf respectively. The rivet features an aluminum alloy body with a natural finish, a carbon steel mandrel with zinc-coated chromium finish, and conforms to industry standards for quality and performance.
Product Specifications
Nominal Dimensions Body Length
51.0 mm | 2.0 in
Nominal Dimensions Diameter
6.4 mm | 1/4 in
Nominal Dimensions Drillhole Size
6.8 to 7.0 mm | 0.268 to 0.276 in
Nominal Dimensions Head Diameter
12.0 mm | 0.472 in
Nominal Dimensions Head Thickness
1.80 mm | 0.071 in
Nominal Dimensions Mandrel Diameter
3.6 mm | 0.142 in
Nominal Dimensions Maximum Grip Range
32.0 mm | 1.259 in
Nominal Dimensions Minimum Grip Range
18.0 mm | 0.710 in
Nominal Forces Nominal Shear Force
250 kgf | 551 lbf
Nominal Forces Nominal Tensile Force
320 kgf | 706 lbf
Technical Specs Body Finish
Natural
Technical Specs Body Material
Aluminum Alloy (ALmg 3.0/5.0)
Technical Specs Brands
Ornit | TPR
Technical Specs Carton Quantity
1000
Technical Specs Mandrel Finish
Zinc Coated Chromium (Cr) VI Free
Technical Specs Mandrel Material
Carbon Steel
