Aluminum/Magnesium/Silicon Alloy Tube - 25.4mm OD
Aluminum/Magnesium/Silicon Alloy Tube - 25.4mm OD
SKU:ALU-b04d52
Durable aluminum alloy tube with 25.4mm OD and high tensile strength. Ideal for institutional procurement.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
Aluminum/Magnesium/Silicon Alloy Tube - 25.4mm OD
$29.99
Quantity: 1
Claim Your Seller Account
Aluminum/Magnesium/Silicon Alloy Tube - 25.4mm OD
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Aluminum/Magnesium/Silicon Alloy Tube with a 25.4mm outside diameter and 3.25mm wall thickness is a durable and versatile choice for various applications. Manufactured by Goodfellow Corp., this hard-tempered tube offers a high tensile strength of 245.00 to 325.00 MPa and a modulus of elasticity of 69.0 GPa. With excellent thermal conductivity and electrical resistivity, this tube meets stringent industry standards and is ideal for institutional and government procurement needs.
Product Specifications
Electrical Properties Electrical Resistivity
3.4 to 3.8 µΩ·cm
Electrical Properties Temperature Coefficient
0.00310 to 0.00350 k-1
Material Material
Aluminum/Magnesium/SiliconAlloys are mixtures of a metal with other elements, the precise combination being governed by the required properties. Alloys are generally considered to be metallic in nature i.e. they have good thermal and electrical conductivities).Alloys can be manufactured by various routes, the most widely used being to melt the constituents together and to cool the resultant mixture to form a single or multi-phase solid.
Mechanical Properties Elongation At Break
< 20.0 %
Mechanical Properties Hardness Brinell
65 to 95
Mechanical Properties Modulus Of Elasticity
69.0 GPa
Mechanical Properties Tensile Strength
245.00 to 325.00 MPa
Physical Properties Density
2.690 g·cm-3
Specifications Form
Tube
Specifications Inside Diameter
18.9 mm
Specifications Length
100 to 1000 mm
Specifications Outside Diameter
25.4 mm
Specifications Temper
Hard
Specifications Wall Thickness
3.25 mm
Thermal Properties Coefficient Of Thermal Expansion At 20 To 100
23.000 x10-6 K-1
Thermal Properties Thermal Conductivity At 23 Degree Celsius C T
180.00 to 195.00 W m-1K-1
Tolerances Tolerance For 100 Millimeter Mm Length Round
-1 % | +5 %
Tolerances Tolerance For 2 Millimeter Mm Outside Diameter
0.5 mm
Tolerances Tolerance For 5 Millimeter Mm Outside Diameter
5 %
Tolerances Wall Thickness Tolerance
10 %
Type Type
AlloyAlloys are mixtures of a metal with other elements, the precise combination being governed by the required properties. Alloys are generally considered to be metallic in nature i.e. they have good thermal and electrical conductivities). Alloys can be manufactured by various routes, the most widely used being to melt the constituents together and to cool the resultant mixture to form a single or multi-phase solid.
