Aluminum/Magnesium/Silicon Alloy Wire, 0.05mm Diameter
Aluminum/Magnesium/Silicon Alloy Wire, 0.05mm Diameter
SKU:ALU-0ede30
High-quality Aluminum/Magnesium/Silicon Alloy Wire, 0.05mm dia, ideal for strength, flexibility & conductivity.
Regular price
$45.99
Regular price
Sale price
$45.99
Unit price
per
Initiate Order
Aluminum/Magnesium/Silicon Alloy Wire, 0.05mm Diameter
$45.99
Quantity: 1
Claim Your Seller Account
Aluminum/Magnesium/Silicon Alloy Wire, 0.05mm Diameter
$45.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Aluminum/Magnesium/Silicon (Al98/Mg 1/Si 0.6) Wire is a high-quality alloy wire ideal for various applications requiring strength, flexibility, and electrical conductivity. With a diameter of 0.05mm and lengths ranging from 5 to 100m, this wire offers excellent mechanical properties including a tensile strength of 150.00 to 430.00 MPa and a modulus of elasticity of 70.0 GPa. It meets industry standards for thermal conductivity, electrical resistivity, and shear strength, making it a reliable choice for both consumer and institutional buyers.
Product Specifications
Electrical Properties Electrical Resistivity
3.4 to 3.8 µΩ·cm
Electrical Properties Temperature Coefficient
0.00300 k-1
Material Material
Aluminum/Magnesium/SiliconAlloys are mixtures of a metal with other elements, the precise combination being governed by the required properties. Alloys are generally considered to be metallic in nature i.e. they have good thermal and electrical conductivities).Alloys can be manufactured by various routes, the most widely used being to melt the constituents together and to cool the resultant mixture to form a single or multi-phase solid.
Mechanical Properties Elongation At Break
< 20.0 %
Mechanical Properties Hardness Brinell
10 to 100
Mechanical Properties Izod Impact Strength
27.0 to 34.0 J m-1
Mechanical Properties Modulus Of Elasticity
70.0 GPa
Mechanical Properties Shear Strength
160 to 200 MPa
Mechanical Properties Tensile Strength
150.00 to 430.00 MPa
Physical Properties Density
2.690 g·cm-3
Specifications Diameter
0.05 mm
Specifications Form
Wire
Specifications Length
5 to 100 m
Specifications Temper
As Drawn
Thermal Properties Coefficient Of Thermal Expansion At 20 To 100
23.000 x10-6 K-1
Thermal Properties Specific Heat At 23 Degree Celsius C Temperat
904.0 J K-1 kg-1
Thermal Properties Thermal Conductivity At 23 Degree Celsius C T
180.00 to 193.00 W m-1K-1
Tolerances Diameter Tolerance
10 %
Tolerances Length Round Tolerance
-1 % | +5 %
Type Type
AlloyAlloys are mixtures of a metal with other elements, the precise combination being governed by the required properties. Alloys are generally considered to be metallic in nature i.e. they have good thermal and electrical conductivities). Alloys can be manufactured by various routes, the most widely used being to melt the constituents together and to cool the resultant mixture to form a single or multi-phase solid.
Analysis Chromium Cr
2500 ppm
Analysis Copper Cu
2500 ppm
Analysis Manganese Mn
1 %
Analysis Silicon Si
6000 ppm
