Aluminum/Magnesium/Silicon Alloy Wire - 0.125mm Diameter
Aluminum/Magnesium/Silicon Alloy Wire - 0.125mm Diameter
SKU:ALU-dc7ea6
High-quality Aluminum/Magnesium/Silicon Wire - 0.125mm Diameter, Excellent Performance & Durability
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
Aluminum/Magnesium/Silicon Alloy Wire - 0.125mm Diameter
$29.99
Quantity: 1
Claim Your Seller Account
Aluminum/Magnesium/Silicon Alloy Wire - 0.125mm Diameter
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Aluminum/Magnesium/Silicon (Al98/Mg1/Si0.6) Wire offers exceptional quality and versatility for a wide range of applications. With a diameter of 0.125mm and a length range of 5 to 100m, this wire provides superior electrical resistivity, mechanical strength, and thermal conductivity. Manufactured by Goodfellow Corp., this wire meets stringent industry standards and is ideal for both consumer and institutional buyers seeking reliable performance and durability. Upgrade your projects with this premium alloy wire that ensures consistent results and reliable performance.
Product Specifications
Electrical Properties Electrical Resistivity
3.4 to 3.8 µΩ·cm
Electrical Properties Temperature Coefficient
0.00300 k-1
Material Material
Aluminum/Magnesium/SiliconAlloys are mixtures of a metal with other elements, the precise combination being governed by the required properties. Alloys are generally considered to be metallic in nature i.e. they have good thermal and electrical conductivities).Alloys can be manufactured by various routes, the most widely used being to melt the constituents together and to cool the resultant mixture to form a single or multi-phase solid.
Mechanical Properties Elongation At Break
< 20.0 %
Mechanical Properties Hardness Brinell
10 to 100
Mechanical Properties Izod Impact Strength
27.0 to 34.0 J m-1
Mechanical Properties Modulus Of Elasticity
70.0 GPa
Mechanical Properties Shear Strength
160 to 200 MPa
Mechanical Properties Tensile Strength
150.00 to 430.00 MPa
Physical Properties Density
2.690 g·cm-3
Specifications Diameter
0.125 mm
Specifications Form
Wire
Specifications Length
5 to 100 m
Specifications Temper
As Drawn
Thermal Properties Coefficient Of Thermal Expansion At 20 To 100
23.000 x10-6 K-1
Thermal Properties Specific Heat At 23 Degree Celsius C Temperat
904.0 J K-1 kg-1
Thermal Properties Thermal Conductivity At 23 Degree Celsius C T
180.00 to 193.00 W m-1K-1
Tolerances Diameter Tolerance
10 %
Tolerances Length Round Tolerance
-1 % | +5 %
Type Type
AlloyAlloys are mixtures of a metal with other elements, the precise combination being governed by the required properties. Alloys are generally considered to be metallic in nature i.e. they have good thermal and electrical conductivities). Alloys can be manufactured by various routes, the most widely used being to melt the constituents together and to cool the resultant mixture to form a single or multi-phase solid.
Analysis Chromium Cr
2500 ppm
Analysis Copper Cu
2500 ppm
Analysis Manganese Mn
1 %
Analysis Silicon Si
6000 ppm
