AMT 315B-95 Heavy Duty Straight Centrifugal Pump
AMT 315B-95 Heavy Duty Straight Centrifugal Pump
SKU:PRO-024875
Reliable, low maintenance, and corrosion-resistant Straight Centrifugal Pump for industrial applications. Customizable options available.
Regular price
$1,545.99
Regular price
Sale price
$1,545.99
Unit price
per
Initiate Order
AMT 315B-95 Heavy Duty Straight Centrifugal Pump
$1,545.99
Quantity: 1
Claim Your Seller Account
AMT 315B-95 Heavy Duty Straight Centrifugal Pump
$1,545.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The AMT 315B-95 Heavy Duty Straight Centrifugal Pump is a robust solution for liquid and chemical transfer, heating, cooling, booster services, and various industrial applications. Constructed with Stainless Steel, Naval Bronze, or Cast Iron, it offers resistance to rust and corrosion. The semi-open impeller with self-cleaning capability is ideal for handling muddy or dirty liquids. Featuring Type 21 mechanical seal and O-ring casing seal, this pump ensures reliability and low maintenance. With options like different motor phases, seal materials, and high flow designs, it meets diverse institutional procurement requirements.
Product Specifications
Specifications 0
Stainless Steel, Naval Bronze & Cast Iron ConstructionBuna-N or Viton® Mechanical Seal and O-Rings depending on Models, Optional Silicon Carbide AvailableStainless Steel HardwareNEMA TEFC Single and Three Phase Motors Depending on the ModelStainless Steel Motor ShaftOptional Mounting Base Available for 182/184/215 JM FramesSelf-cleaning ImpellerDischarge Rotates in 90º IncrementsMaximum Working Pressure to 150 PSIMax. Temperature 200ºF (Viton®), 180ºF (Buna-N)Optional Seal Wash Port and Hose is Available on All Models"Off-the-Shelf" Availability for Many ModelsPedestal Version Models Available for Frame Models 145/182/184JM
Specifications Curve
G
Specifications Customs Code
HTS Code 8413702005
Specifications Enclosure Rating
TEFC
Specifications Full Load Current
8/4 A
Specifications Height
10 in | 243.84 mm
Specifications Inlet Size
2 in
Specifications Installed Options
Seal Wash Installed: 1/8" NPT access and rubber hose w/ 1/2" NPT male thread end (A220-90) | Silicon Carbide/Viton Seal Installed (315X-302-VS)
Specifications Length
17 in | 441.96 mm
Specifications Manufacturer
American Machine and Tool Company
Specifications Max Flow Rate
500 gpm
Specifications Moc
Cast Iron
Specifications Model
315B-95
Specifications Motor Frame
56J
Specifications Phase
3
Specifications Porting Position
1 1/2 in
Specifications Power
3 hp
Specifications Seal Material
Buna-N
Specifications Sku
AT315B95SP
Specifications Temperature
180 ºF
Specifications Voltage At 60 Hz
230/460 V
Specifications Weight
34.02 | 75 | 74 lbs
Specifications Width
11 in | 269.24 mm
