AMT 5341-95 Interchangeable Immersion & Suction Coolant/Oil Pump
AMT 5341-95 Interchangeable Immersion & Suction Coolant/Oil Pump
SKU:PRO-9344a3
Dependable AMT 5341-95 Immersion & Suction Coolant/Oil Pump with Stainless Steel Impeller for efficient coolant circulation and spraying.
Regular price
$399.99
Regular price
Sale price
$399.99
Unit price
per
Initiate Order
AMT 5341-95 Interchangeable Immersion & Suction Coolant/Oil Pump
$399.99
Quantity: 1
Claim Your Seller Account
AMT 5341-95 Interchangeable Immersion & Suction Coolant/Oil Pump
$399.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The AMT 5341-95 Interchangeable Immersion & Suction Coolant/Oil Pump is a reliable and cost-effective solution designed for the circulation and spraying of coolants and cutting oils. Featuring a Stainless Steel impeller for enhanced corrosion/erosion resistance, this pump is ideal for handling solids and fine contaminants. With a 1/8 hp motor operating at 3450 RPM and the ability to handle viscosity up to 500 SSU, this pump is fully interchangeable with units used in most imported machine tools. Suitable for nonflammable liquids, the AMT pump ensures durability and low maintenance, making it a standard replacement in the machine tool industry.
Product Specifications
Specifications 0
Cast Iron ConstructionStainless Steel ImpellerCarbon Steel ShaftCarbon/Ceramic Shaft SealSelf Priming up to 2' - Maximum Suction LiftPumps Must be Mounted Above Liquid
Specifications Curve
A
Specifications Customs Code
HTS Code 8413702005
Specifications Full Load Current
0.3/0.19 A
Specifications Full Load Voltage
230/460 V
Specifications Height
15 in | 381.00 mm
Specifications Impeller Material
Stainless
Specifications Inlet Size
0.38 in
Specifications Length
8 in | 203.20 mm
Specifications Manufacturer
American Machine and Tool Company
Specifications Max Flow Water
56 gpm
Specifications Model
5341-95
Specifications Motor Rpm
3450 rpm
Specifications Old Fuji Pn
VKN-051A
Specifications Phase
3
Specifications Power
1/8 hp
Specifications Seal Material
Carbon/Ceramic
Specifications Sku
AT534195SP
Specifications Temperature
180 ºF
Specifications Toshiba Pn
OPF-60M
Specifications Type
Interchangeable Suction Pumps
Specifications Weight
14 | 6.35 | 14 lbs
Specifications Width
8 in | 203.20 mm
Specifications Yasukawa Pn
VFPC-061F
