AMT 5350-95 Interchangeable Immersion & Suction Coolant/Oil Pump
AMT 5350-95 Interchangeable Immersion & Suction Coolant/Oil Pump
SKU:PRO-6a87e4
Dependable AMT 5350-95 Interchangeable Coolant/Oil Pump for efficient coolant and oil circulation on machine tools. Stainless Steel impeller, high flow rate, and low maintenance.
Regular price
$289.99
Regular price
Sale price
$289.99
Unit price
per
Initiate Order
AMT 5350-95 Interchangeable Immersion & Suction Coolant/Oil Pump
$289.99
Quantity: 1
Claim Your Seller Account
AMT 5350-95 Interchangeable Immersion & Suction Coolant/Oil Pump
$289.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The AMT 5350-95 Interchangeable Coolant/Oil Pump is a reliable and cost-effective solution designed for the circulation and spraying of coolants and cutting oils in machine tools. Featuring a Stainless Steel impeller and durable construction, this pump operates at 3450 RPM and is available in 115/230 V AC single phase and 230/460 V AC three phase models. With a maximum flow of 56 GPM and the ability to handle viscosity up to 500 SSU, this pump is a standard replacement in the machine tool industry. Ideal for both domestic and foreign-made machine tools, the AMT 5350-95 ensures efficient coolant and oil circulation with low maintenance requirements.
Product Specifications
Specifications 0
Cast Iron ConstructionStainless Steel ImpellerCarbon Steel ShaftCarbon/Ceramic Shaft SealSelf Priming up to 2' - Maximum Suction LiftPumps Must be Mounted Above Liquid
Specifications Curve
B
Specifications Customs Code
HTS Code 8413702005
Specifications Full Load Current
3.0/1.5 A
Specifications Full Load Voltage
115/230 V
Specifications Height
15 in | 381.00 mm
Specifications Impeller Material
Stainless
Specifications Inlet Size
3/4 in
Specifications Length
8 in | 203.20 mm
Specifications Manufacturer
American Machine and Tool Company
Specifications Max Flow Water
56 gpm
Specifications Model
5350-95
Specifications Motor Rpm
3450 rpm
Specifications Old Fuji Pn
VKN-061A
Specifications Phase
1
Specifications Power
1/4 hp
Specifications Seal Material
Carbon/Ceramic
Specifications Sku
AT535095SP
Specifications Temperature
180 ºF
Specifications Toshiba Pn
OPF-100M
Specifications Type
Interchangeable Suction Pumps
Specifications Weight
12.25 | 27 | 27 lbs
Specifications Width
8 in | 203.20 mm
Specifications Yasukawa Pn
VFPC-101JF
