The AMT 5381-95 Interchangeable Immersion & Suction Coolant/Oil Pump is a reliable and cost-effective solution designed for circulation, spraying coolants, and cutting oils. Featuring a Stainless Steel impeller for enhanced corrosion resistance and durability, this pump is fully interchangeable with units furnished on most imported machine tools. With a power of 1/8 HP, 230/460V three-phase motor, and a maximum flow of 56 GPM, this pump is ideal for handling fine contaminants and solids, making it a standard replacement for the machine tool industry.
Product Specifications
Specifications 0
Cast Iron ConstructionStainless Steel ImpellerCarbon Steel ShaftSealless Design for Pumping AbrasivesPumps Liquids Down to 2"Ideally Suited for Pumping Fine Contaminants
Specifications Curve
A
Specifications Customs Code
HTS Code 8413702005
Specifications Full Load Current
0.3/0.19 A
Specifications Full Load Voltage
230/460 V
Specifications Height
13 in | 330.20 mm
Specifications Impeller Material
Stainless
Specifications Inlet Size
0.38 in
Specifications Length
6 in | 152.40 mm
Specifications Manufacturer
American Machine and Tool Company
Specifications Max Flow Water
56 gpm
Specifications Model
5381-95
Specifications Motor Rpm
3450 rpm
Specifications Old Fuji Pn
VKN-051A
Specifications Phase
3
Specifications Power
1/8 hp
Specifications Seal Material
Sealless Design
Specifications Sku
AT538195SP
Specifications Temperature
180 ºF
Specifications Toshiba Pn
OPF-60M
Specifications Type
Interchangeable Immersion Pumps
Specifications Weight
15 | 6.80 | 15 lbs
Specifications Width
6 in | 152.40 mm
Specifications Yasukawa Pn
VFPC-061DIF
