AMT 5400-95 Stainless Steel Impeller Coolant Pump

Name: AMT 5400-95 Stainless Steel Impeller Coolant Pump
Brand: Springer Pumps, LLC
SKU: PRO-b87e64
Price: 499.99 USD
Availability: OutOfStock

SKU:PRO-b87e64

AMT 5400-95 Stainless Steel Impeller Coolant Pump - Reliable, Cost-effective, Ideal for Machining Applications

$499.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The AMT 5400-95 Interchangeable Immersion & Suction Coolant Pump is a reliable and cost-effective solution for circulating and spraying coolants and cutting oils in machine tools. With a durable Stainless Steel impeller and sealless design, this pump is ideal for handling fine contaminants and solids. Operating at 3450 RPM with a 1/2 HP motor, it offers a maximum flow of 56 GPM and can handle liquids down to 2". Fully interchangeable with units from major machine tool brands, the AMT 5400-95 is a dependable choice for industrial applications.

Product Specifications

Specifications 0

Cast Iron ConstructionStainless Steel ImpellerCarbon Steel ShaftSealless Design for Pumping AbrasivesPumps Liquids Down to 2"Ideally Suited for Pumping Fine Contaminants

Specifications Curve

Specifications Customs Code

HTS Code 8413702005

Specifications Full Load Current

1.8/1.25 A

Specifications Full Load Voltage

230/460 V

Specifications Height

8 in | 203.20 mm

Specifications Impeller Material

Stainless

Specifications Inlet Size

3/4 in

Specifications Length

14 in | 355.60 mm

Specifications Manufacturer

American Machine and Tool Company

Specifications Max Flow Water

56 gpm

Specifications Model

5400-95

Specifications Motor Rpm

3450 rpm

Specifications Old Fuji Pn

VKN-081A

Specifications Phase

Specifications Power

1/2 hp

Specifications Seal Material

Sealless Design

Specifications Sku

AT540095SP

Specifications Temperature

180 ÂºF

Specifications Toshiba Pn

OPF-250M

Specifications Type

Interchangeable Immersion Pumps

Specifications Weight

18.14 | 40 | 40 lbs

Specifications Width

7 in | 177.80 mm

Specifications Yasukawa Pn

VFPC-250JF
