AMT 5792-95 Submersible Drainage Pump
AMT 5792-95 Submersible Drainage Pump
SKU:PRO-ce5fd6
Reliable AMT 5792-95 Submersible Drainage Pump for efficient water removal in various applications. Durable construction with built-in thermal protection and automatic float switch.
Regular price
$689.00
Regular price
Sale price
$689.00
Unit price
per
Initiate Order
AMT 5792-95 Submersible Drainage Pump
$689.00
Quantity: 1
Claim Your Seller Account
AMT 5792-95 Submersible Drainage Pump
$689.00
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The AMT 5792-95 Submersible Drainage Pump is a versatile solution for various applications such as sump and drainage pits, construction sites, and cooling towers. This pump features a durable construction of stainless steel, cast iron, or plastic, with built-in thermal protection and a Triplex Seal System for enhanced reliability. Equipped with an automatic float switch, this pump ensures efficient water removal, while the clog-resistant impellers promote consistent performance. With a 1/2 HP motor and 2" NPT inlet size, the AMT 5792-95 offers a maximum temperature of 104°F, making it suitable for demanding environments.
Product Specifications
Specifications 0
UL/CSA ListedAutomatic Float Switch (except SS Model 5780-98)Double Mechanical Seal Construction580 Series; Plastic Submersibles Include Hose Adapters104º F Max TemperatureSuction Screen115 VAC UL/SJTW Cord with 3 Prong PlugCarry Handle Built InThermal Protection
Specifications Curve
F
Specifications Customs Code
HTS Code 8413702004
Specifications Full Load Current
6.9 A
Specifications Height
16 in | 408.94 mm
Specifications Inlet Size
2" NPT
Specifications Length
20 in | 508.00 mm
Specifications Manufacturer
American Machine and Tool Company
Specifications Model
5792-95
Specifications Note
Electric supply for ALL motors must be with ± 10% of nameplate voltage.
Specifications Power
1/2 hp
Specifications Sku
AT579295SP
Specifications Temperature
104 ºF
Specifications Type
Drainage
Specifications Voltage Ac At 60 Hz
115 V
Specifications Weight
19.05 | 42 | 42 lbs
Specifications Width
7 in | 187.96 mm
