AMT 5792-95 Submersible Drainage Utility Pump

AMT 5792-95 Submersible Drainage Utility Pump

PRO-ce5fd6

AMT 5792-95 Submersible Drainage Utility Pump - Reliable, cost-effective, and efficient pump for various applications. Stainless Steel, Cast Iron, and Plastic Construction.

$565.99
$565.99
Sale

Initiate Order

AMT 5792-95 Submersible Drainage Utility Pump

AMT 5792-95 Submersible Drainage Utility Pump

$565.99

Quantity: 1

Claim Your Seller Account

AMT 5792-95 Submersible Drainage Utility Pump

AMT 5792-95 Submersible Drainage Utility Pump

$565.99

Quantity: 1

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details
The AMT 5792-95 Submersible Drainage Utility Pump is a high-performance solution designed for a wide range of applications, from sump pits to construction drainage. Featuring a durable Stainless Steel, Cast Iron, and Plastic Construction, this pump offers reliability, cost-effectiveness, and low maintenance. Its Triplex Seal System with Double Mechanical Seals Plus Shaft Seal ensures optimal performance and longevity. With a built-in Thermal Protection, Automatic Float Switch, and a 115 VAC UL/SJT Cord with 3 Prong Plug, this pump is equipped for efficient and safe operation. Measuring 20" in length, 7" in width, and 16" in height, this pump is a versatile and essential tool for clear water removal.

Product Specifications

Specifications 0
UL/CSA ListedAutomatic Float Switch (except SS Model 5780-98)Double Mechanical Seal Construction580 Series; Plastic Submersibles Include Hose Adapters104º F Max TemperatureSuction Screen115 VAC UL/SJTW Cord with 3 Prong PlugCarry Handle Built InThermal Protection
Specifications Curve
F
Specifications Customs Code
HTS Code 8413702004
Specifications Full Load Current
6.9 A
Specifications Height
16 in | 408.94 mm
Specifications Inlet Size
2" NPT
Specifications Length
20 in | 508.00 mm
Specifications Manufacturer
American Machine and Tool Company
Specifications Model
5792-95
Specifications Note
Electric supply for ALL motors must be with ± 10% of nameplate voltage.
Specifications Power
1/2 hp
Specifications Sku
AT579295SP
Specifications Temperature
104 ºF
Specifications Type
Drainage
Specifications Voltage Ac At 60 Hz
115 V
Specifications Weight
19.05 | 42 | 42 lbs
Specifications Width
7 in | 187.96 mm
