Anaconda Sealtite Type EFST Liquid Tight Metal Conduit

Name: Anaconda Sealtite Type EFST Liquid Tight Metal Conduit
Brand: Anamet Electrical, Inc.
SKU: LIQ-fb3298
Price: 199.99 USD
Availability: OutOfStock

SKU:LIQ-fb3298

Flexible, liquid-tight Anaconda Sealtite Type EFST conduit for wiring applications, with hot-dipped zinc galvanized steel core and PVC outer jacket. Ideal for various non-agency approved uses.

$199.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The Anaconda Sealtite Type EFST Liquid Tight Metal Conduit is a versatile solution offering a flexible, liquid-tight raceway for wiring. Constructed with a hot-dipped zinc galvanized steel core and a PVC outer jacket, this conduit ensures durability and reliability. With an IP 67 rating when used with approved connectors, it is ideal for various applications where agency approvals are not required. Designed for General Construction Grade Applications, this conduit has a temperature range of -4ºF to +176ºF (-20ºC to +80ºC), providing consistent performance in a wide range of environments. Anaconda Sealtite Type EFST meets RoHS and WEEE industry certifications, ensuring compliance with environmental standards.

Product Specifications

Application 0

Designed for General Construction Grade ApplicationsTemperature Range: -4ºF to +176ºF (-20ºC to +80ºC)

Installation 0

Designed for General Construction Grade ApplicationsTemperature Range: -4ºF to +176ºF (-20ºC to +80ºC)

Specifications Approx Inside Bend Radius

16 in | 406.4 mm

Specifications Approx Weight Per 100 Ft

314 lbs | 142.43 kg

Specifications Color

GRAY

Specifications Core Material

Galvanized Steel

Specifications Cross Reference

28505 | LA-350 | LT-350

Specifications Electrical Trade Size

3-1/2 in | 91 mm

Specifications Industry Certifications

RoHS WEEE

Specifications Ingress Protection Ip Rating

Ingress Protection (IP) 66/67

Specifications Inside Diameter

3.500 to 3.540 in | 88.900 to 89.916 mm

Specifications Jacket Benefits

Liquid Tight

Specifications Jacket Material

Polyvinyl Chloride (PVC)

Specifications Length

25 ft | 7.62 m

Specifications Optional Colors

Black

Specifications Outside Diameter

3.960 to 4.000 in | 100.584 to 101.600 mm

Specifications Packaging

Standard Package

Specifications Type

EFST

Anaconda Sealtite Type EFST Liquid Tight Metal Conduit
