API Spec 13A Hydrogel for Drilling Applications

Name: API Spec 13A Hydrogel for Drilling Applications
Brand: CB Minerals
SKU: HYD-f4dd76
Price: 39.99 USD
Availability: OutOfStock

SKU:HYD-f4dd76

High-performance API Spec 13A Hydrogel for drilling, with superior fluid loss control and precise specifications for reliable operations.

$39.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

Our API Spec 13A Hydrogel is a sodium bentonite specifically engineered for drilling, boring, tunneling, and construction projects. With a high colloid content of over 85%, light gray to tan color, and precise specifications meeting API Sec. 13A, Section 9 standards, this hydrogel ensures superior performance and reliability in diverse applications. Experience excellent fluid loss control, optimal gel strength, and consistent viscosity for seamless operations.

Product Specifications

Chemical Analysis Aluminum Oxide Al2o3

19.28 %

Chemical Analysis Calcium Oxide Cao

0.38 %

Chemical Analysis Dihydrogen Oxide H2o

7.75 %

Chemical Analysis Iron Oxide Fe2o3

3.4 %

Chemical Analysis Loss On Ignition Loi

4.37 %

Chemical Analysis Magnesium Oxide Mgo

1.67 %

Chemical Analysis Other

0.07 %

Chemical Analysis Potassium Oxide K2o

0.10 %

Chemical Analysis Silicon Dioxide Sio2

60.34 %

Chemical Analysis Sodium Oxide Na2o

2.34 %

Chemical Analysis Titanium Dioxide Tio2

0.22 %

Physical Analysis Barrel Yield

98 bbl/ton

Physical Analysis Barrel Yield Tolerance

4 bbl/ton

Physical Analysis Bulk Density

52 lb/ftÂ³

Physical Analysis Bulk Density Tolerance

3 lb/ftÂ³

Physical Analysis Colloid Content

> 85 %

Physical Analysis Color

Light Gray to Tan

Physical Analysis Fluid Loss

13.5 cmÂ³

Physical Analysis Fluid Loss Tolerance

1 cmÂ³

Physical Analysis Free Swell

24 cmÂ³

Physical Analysis Free Swell Tolerance

4 cmÂ³

Physical Analysis Gel Strength 10 Minute Min

25 min

Physical Analysis Gel Strength 10 Seconds Sec

15 sec

Physical Analysis Gel Strength Tolerance 10 Minute Min

5 min

Physical Analysis Gel Strength Tolerance 10 Seconds Sec

5 sec

Physical Analysis Marsh Funnel Viscosity

45 sec

Physical Analysis Marsh Funnel Viscosity Tolerance

2 sec

Physical Analysis Maximum Residue Wet Shield Analysis Passing Th

4 %

Physical Analysis Maximum Yield Point Ypplastic Viscosity Pv Rat

Physical Analysis Minimum Viscometer Reading At 600 Revolutions

30 cP

Physical Analysis Moisture Content

8 %

Physical Analysis Moisture Content Tolerance

2 %

Physical Analysis Particle Size Passing Through 200 Mesh Sieves

> 79 %

Physical Analysis Potential Of Hydrogen Ph

9.1 pH

Physical Analysis Potential Of Hydrogen Ph Tolerance

0.4 pH

Physical Analysis Residue Wet Shield Analysis Passing Through 20

> 4 %

Physical Analysis Specific Gravity

2.55

Physical Analysis Specific Gravity Tolerance

0.1

Physical Analysis Viscometer Reading At 600 Revolutions Per Minu

38.4 cP

Physical Analysis Viscometer Reading Tolerance At 600 Revolution

4 cP
