Enhance electronics durability with ARONIX® UV Curable Conformal Coatings. This non-solvent coating offers exceptional FPC adhesion, ideal for safeguarding electrode terminals and circuit boards. Benefit from high transparency for corrosion monitoring through the resin. Compliant with Federal procurement standards, these coatings ensure reliable protection in demanding environments.
Product Specifications
Features Features
This is a Non-solvent UV curable conformal coating with good FPC adhesion.This is suitable for protecting electrode terminals and electronic circuit boards.Since the transparency of the resin is high, you can check the corrosion state of the electrode through the resin.
Note Note
Photo Curing Conditions: Metal Halide, UV exposure dose = 1 J/cm² (UV-A)
Specifications Electric Resistance During Moisture Test
Ok
Specifications Glass Adhesive Strength
1,890 N/in²
Specifications Glass Transition Temperature Tg At 1 Hertz Hz Fre
75.2 ºF
Specifications Item Name
Aronix 6754
Specifications Moisture Permeability For 24 Hours H
1.25 g/ft²
Specifications Polyimide Adhesive Strength
13.2 N/in
Specifications Viscosity At 77 Degree Fahrenheit F Temperature
2,500 ~ 8,000 mPa·s
Specifications Water Absorption Rate
1.8 %
