Atkomatic 30400 Series Bronze Solenoid Valve
Atkomatic 30400 Series Bronze Solenoid Valve
SKU:ATK-bcfca8
Optimize fluid control with Atkomatic 30400 Series Solenoid Valve, ideal for gas applications. Semi-direct lift action, EPR seat & seal, -65 to 300 °F, Cv 21.0, Class H coils.
Regular price
$149.99
Regular price
Sale price
$149.99
Unit price
per
Initiate Order
Atkomatic 30400 Series Bronze Solenoid Valve
$149.99
Quantity: 1
Claim Your Seller Account
Atkomatic 30400 Series Bronze Solenoid Valve
$149.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Enhance fluid control with the Atkomatic 30400 Series Bronze Solenoid Valve. This semi-direct lift valve functions at zero pressure differential up to 1500 psig, suitable for gas applications. Featuring EPR seat & seal material, this normally closed valve operates between -65 to 300 °F, optimizing flow with a Cv of 21.0. With Class H coils, threaded cylinder cap, and NEMA coil housing options, it offers robust performance and easy installation. Suitable for a wide range of fluids, this valve guarantees reliability and precision in fluid management.
Product Specifications
Specifications Body Material
Bronze
Specifications Coil Housing
Standard
Specifications Coil Insulation Rating
Class H (180° C)
Specifications Coil Type
Single Wound Molded
Specifications Connection Size
1 1/2 in
Specifications Connection Type
Female NPT
Specifications Cylinder Cap Style
Threaded Cylinder Cap
Specifications Dim X
10 1/8 in
Specifications Dim Y
8.25 in
Specifications Dim Z
5 1/16 in
Specifications Flow Coefficient Cv
21.0
Specifications Fluid Media Type
Gas
Specifications Main Seat Orifice
1 1/2 in
Specifications Operating Pressure
0 to 500 psig | 0 to 34.5 bar
Specifications Position Of Valve De Energized
Normally Closed
Specifications Seat Seal Material
EPR
Specifications Series
30400
Specifications Temperature Range
-65 to 300 ºF | -54 to 149 ºC
Specifications Type
Solenoid Valve
Specifications Voltage
115 VAC
