Atkomatic 30400 Series Bronze Solenoid Valve
Atkomatic 30400 Series Bronze Solenoid Valve
SKU:ATK-9dcecf
Top-tier Atkomatic 30400 Series Solenoid Valve for medium pressure applications, designed for durability and high performance.
Regular price
$265.99
Regular price
Sale price
$265.99
Unit price
per
Initiate Order
Atkomatic 30400 Series Bronze Solenoid Valve
$265.99
Quantity: 1
Claim Your Seller Account
Atkomatic 30400 Series Bronze Solenoid Valve
$265.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Atkomatic 30400 Series Solenoid Valve is a top-of-the-line solution for medium pressure applications. With a durable bronze construction, this valve operates flawlessly from 0 to 1500 psig, handling various fluids with ease. From extreme temperatures ranging from -65 to 300 °F to a wide range of compatible fluids like air, gasses, hydraulic fluids, and more, this valve is designed to deliver consistent performance under challenging conditions. Offering configurable options for seat materials and body seals, this valve ensures compatibility with different fluid types and pressures. Additionally, it is equipped with optional features like coil housings for NEMA ratings, manual opening devices, and valve position indicators.
Product Specifications
Specifications Body Material
Bronze
Specifications Coil Housing
Standard
Specifications Coil Insulation Rating
Class H (180° C)
Specifications Coil Type
Single Wound Molded
Specifications Connection Size
3/8 in
Specifications Connection Type
Female NPT
Specifications Cylinder Cap Style
Threaded Cylinder Cap
Specifications Dim X
8 5/8 in
Specifications Dim Y
7 3/4 in
Specifications Dim Z
2.6875 in
Specifications Flow Coefficient Cv
2.70
Specifications Fluid Media Type
Gas
Specifications Main Seat Orifice
.375 in
Specifications Operating Pressure
0 to 1500 psig | 0 to 104 bar
Specifications Position Of Valve De Energized
Normally Open
Specifications Seat Seal Material
EPR
Specifications Series
30400
Specifications Temperature Range
-65 to 300 ºF | -54 to 149 ºC
Specifications Type
Solenoid Valve
Specifications Voltage
115 VAC
