Atkomatic 30400 Series Medium Pressure Solenoid Valve
Atkomatic 30400 Series Medium Pressure Solenoid Valve
SKU:ATK-ebb01f
Versatile and durable Bronze Solenoid Valve for medium pressure fluid applications. Wide temperature range. Teflon seal materials.
Regular price
$189.99
Regular price
Sale price
$189.99
Unit price
per
Initiate Order
Atkomatic 30400 Series Medium Pressure Solenoid Valve
$189.99
Quantity: 1
Claim Your Seller Account
Atkomatic 30400 Series Medium Pressure Solenoid Valve
$189.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Atkomatic 30400 Series Solenoid Valve is engineered for versatility and durability in fluid applications. Constructed with high-quality bronze material, this valve offers semi-direct lift action for efficient operation even at zero pressure differential. With a wide temperature range from -65°F to 300°F and the ability to handle fluids up to 40 SUS viscosity, this valve is suitable for various applications. It features Teflon seat and seal materials, ensuring reliable performance. From air and gases to hydraulic fluids and cryogenic fluids, this valve is designed to meet the demands of industrial settings.
Product Specifications
Specifications Body Material
Bronze
Specifications Coil Housing
Standard
Specifications Coil Insulation Rating
Class H (180° C)
Specifications Coil Type
Single Wound Molded
Specifications Connection Size
2 in
Specifications Connection Type
Female NPT
Specifications Cylinder Cap Style
Flanged Cylinder Cap
Specifications Dim X
13 3/16 in
Specifications Dim Y
10 5/16 in
Specifications Dim Z
6 1/8 in
Specifications Flow Coefficient Cv
43.0
Specifications Fluid Media Type
Liquid up to 40 SUS
Specifications Main Seat Orifice
2 in
Specifications Operating Pressure
0 to 500 psig | 0 to 34.5 bar
Specifications Position Of Valve De Energized
Normally Closed
Specifications Seat Seal Material
EPR
Specifications Series
30400
Specifications Temperature Range
-65 to 300 ºF | -54 to 149 ºC
Specifications Type
Solenoid Valve
Specifications Voltage
115 VAC
