Atkomatic 30800 Series Solenoid Valve
Atkomatic 30800 Series Solenoid Valve
SKU:ATK-9cd0c8
High-pressure stainless steel solenoid valve with semi-direct lift action, suitable for a variety of fluid applications
Regular price
$299.99
Regular price
Sale price
$299.99
Unit price
per
Initiate Order
Atkomatic 30800 Series Solenoid Valve
$299.99
Quantity: 1
Claim Your Seller Account
Atkomatic 30800 Series Solenoid Valve
$299.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Atkomatic 30800 Series Solenoid Valve is a high-pressure, stainless steel valve designed for a variety of fluid applications. With stainless steel construction, semi-direct lift action, and the ability to handle fluids with viscosity up to 150 SUS, this valve operates efficiently even at zero pressure differential. It features optional seat materials, removable body inserts, and coil housings available in different NEMA ratings. Suitable for use with air, gasses, liquids, and more, this valve is durable, versatile, and reliable for institutional and consumer needs.
Product Specifications
Specifications Body Material
Stainless Steel
Specifications Body Style
Flanged Cylinder Cap
Specifications Coil Housing
Standard
Specifications Coil Insulation Rating
Class H (180° C)
Specifications Coil Type
Single Wound Molded
Specifications Connection Size
1 1/2 in
Specifications Connection Type
Female NPT
Specifications Dim X
10 1/2 in
Specifications Dim Y
8 3/8 in
Specifications Dim Z
7 5/8 in
Specifications Flow Coefficient Cv
21.5
Specifications Fluid Media Type
Liquid from 41 SUS to 150 SUS
Specifications Main Seat Orifice
1 1/2 in
Specifications Operating Pressure
0 to 3000 psig | 0 to 207 bar
Specifications Position Of Valve De Energized
Normally Closed
Specifications Seat Seal Material
Teflon®
Specifications Series
30800
Specifications Temperature Range
-423 to 500 ºF | -253 to 260 ºC
Specifications Type
Solenoid Valve
Specifications Voltage
115 VAC
