Atkomatic 30800 Series Stainless Steel Solenoid Valve
Atkomatic 30800 Series Stainless Steel Solenoid Valve
SKU:ATK-1b4055
High-pressure stainless steel solenoid valve for versatile fluid applications, durable and corrosion-resistant.
Regular price
$299.99
Regular price
Sale price
$299.99
Unit price
per
Initiate Order
Atkomatic 30800 Series Stainless Steel Solenoid Valve
$299.99
Quantity: 1
Claim Your Seller Account
Atkomatic 30800 Series Stainless Steel Solenoid Valve
$299.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Atkomatic 30800 Series Solenoid Valve is a high-pressure stainless steel valve designed for a variety of fluid applications. Constructed with 316 stainless steel and CF8M cast parts, it offers corrosion resistance and durability. With a semi-direct lift action, it operates effectively down to zero pressure differential and can handle media temperatures ranging from -423°F to +500°F. This valve is suitable for a wide range of fluids including air, liquids, hydraulic fluids, steam, and corrosive fluids. With optional seat materials and coil housing configurations, this valve is versatile and reliable for demanding applications.
Product Specifications
Specifications Body Material
Stainless Steel
Specifications Body Style
Screwed Cylinder Cap
Specifications Coil Housing
Standard
Specifications Coil Insulation Rating
Class H (180° C)
Specifications Coil Type
Single Wound Molded
Specifications Connection Size
2 in
Specifications Connection Type
Female NPT
Specifications Dim X
12 3/8 in
Specifications Dim Y
9 13/16 in
Specifications Dim Z
7 in
Specifications Flow Coefficient Cv
45.0
Specifications Fluid Media Type
Liquid from 41 SUS to 150 SUS
Specifications Main Seat Orifice
2 in
Specifications Operating Pressure
0 to 500 psig | 0 to 34.5 bar
Specifications Position Of Valve De Energized
Normally Closed
Specifications Seat Seal Material
Viton®
Specifications Series
30800
Specifications Temperature Range
-15 to 400 ºF | -29 to 204 ºC
Specifications Type
Solenoid Valve
Specifications Voltage
115 VAC
