Atkomatic 6000 Series Bronze Solenoid Valve
Atkomatic 6000 Series Bronze Solenoid Valve
SKU:ATK-44f238
Reliable Atkomatic 6000 Series Bronze Solenoid Valve for precise fluid control in various applications. Operates at up to 1500 psig with a wide temperature range of -65ºF to 275ºF.
Regular price
$399.99
Regular price
Sale price
$399.99
Unit price
per
Initiate Order
Atkomatic 6000 Series Bronze Solenoid Valve
$399.99
Quantity: 1
Claim Your Seller Account
Atkomatic 6000 Series Bronze Solenoid Valve
$399.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Experience superior fluid control with the Atkomatic 6000 Series Bronze Solenoid Valve. This pilot-piston valve operates at pressures up to 1500 psig, offering reliable performance for a variety of fluid applications. With a wide temperature range, from -65ºF to 275ºF, and compatibility with liquids and gases, this valve is suitable for diverse industrial settings. Featuring robust construction with bronze and stainless steel materials, along with optional seat seal materials for different fluid types, this valve ensures longevity and efficiency in your operations. Additionally, the coil housing options cater to different environmental requirements, making it a versatile choice for your fluid control needs.
Product Specifications
Specifications Body Material
Bronze
Specifications Coil Housing
Standard
Specifications Coil Insulation Rating
Class H (180° C)
Specifications Coil Type
Single Wound Molded
Specifications Connection Size
1 in
Specifications Connection Type
Female NPT
Specifications Cv
9.5
Specifications Dim X
8.25 in
Specifications Dim Y
7 in
Specifications Dim Z
4 in
Specifications Fluid Media Type
Liquid from 41 SUS to 150 SUS
Specifications Main Seat Orifice
1 in
Specifications Operating Pressure
5 to 500 psig
Specifications Position Of Valve De Energized
Normally Closed
Specifications Seat Seal Material
Buna N
Specifications Series
6000
Specifications Temperature Range
-65 to 275 ºF | -54 to 135 ºC
Specifications Type
Solenoid Valve
Specifications Voltage
110 VAC
