Atkomatic 6000 Series Bronze Solenoid Valve
Atkomatic 6000 Series Bronze Solenoid Valve
SKU:ATK-5552be
Durable Atkomatic 6000 Series Solenoid Valve for reliable medium-pressure fluid control. Compliant with Federal standards.
Regular price
$249.99
Regular price
Sale price
$249.99
Unit price
per
Initiate Order
Atkomatic 6000 Series Bronze Solenoid Valve
$249.99
Quantity: 1
Claim Your Seller Account
Atkomatic 6000 Series Bronze Solenoid Valve
$249.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Atkomatic 6000 Series Solenoid Valve is a reliable choice for medium-pressure fluid applications, offering a pressure range of 0 to 1500 psig. Built with bronze material, this valve is suitable for temperatures ranging from -65 to 300°F. With a Cv of 9.5 and voltage rating of 110 VAC, it provides efficient operation. This valve is compliant with Federal/DoD procurement standards, ensuring quality and performance for institutional buyers.
Product Specifications
Specifications Body Material
Bronze
Specifications Coil Housing
Standard
Specifications Coil Insulation Rating
Class H (180° C)
Specifications Coil Type
Single Wound Molded
Specifications Connection Size
1 in
Specifications Connection Type
Female NPT
Specifications Cv
9.5
Specifications Dim X
8.25 in
Specifications Dim Y
7 in
Specifications Dim Z
4 in
Specifications Fluid Media Type
Liquid up to 40 SUS
Specifications Main Seat Orifice
1 in
Specifications Operating Pressure
5 to 500 psig
Specifications Position Of Valve De Energized
Normally Closed
Specifications Seat Seal Material
EPR
Specifications Series
6000
Specifications Temperature Range
-65 to 300 ºF | -54 to 149 ºC
Specifications Type
Solenoid Valve
Specifications Voltage
110 VAC
