Atkomatic 6000 Series Bronze Solenoid Valve
Atkomatic 6000 Series Bronze Solenoid Valve
SKU:ATK-e9dd28
Reliable Atkomatic 6000 Series Solenoid Valve for precise fluid control in institutional applications.
Regular price
$249.99
Regular price
Sale price
$249.99
Unit price
per
Initiate Order
Atkomatic 6000 Series Bronze Solenoid Valve
$249.99
Quantity: 1
Claim Your Seller Account
Atkomatic 6000 Series Bronze Solenoid Valve
$249.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Meet your fluid control needs with the Atkomatic 6000 Series Bronze Solenoid Valve. This pilot-piston valve operates at pressures up to 1500 psig, suitable for a variety of fluid applications. With a wide temperature range, durable bronze construction, and multiple seal material options, this valve offers versatility and reliability. Available in normally closed configuration with 1/2 inch connection size, this valve is designed for liquid up to 40 SUS, making it ideal for institutional and government procurement requirements.
Product Specifications
Specifications Body Material
Bronze
Specifications Coil Housing
Standard
Specifications Coil Insulation Rating
Class H (180° C)
Specifications Coil Type
Single Wound Molded
Specifications Connection Size
1/2 in
Specifications Connection Type
Female NPT
Specifications Cv
3.50
Specifications Dim X
7 1/8 in
Specifications Dim Y
6 1/4 in
Specifications Dim Z
3 in
Specifications Fluid Media Type
Liquid up to 40 SUS
Specifications Main Seat Orifice
.5 in
Specifications Operating Pressure
5 to 500 psig
Specifications Position Of Valve De Energized
Normally Closed
Specifications Seat Seal Material
EPR
Specifications Series
6000
Specifications Temperature Range
-65 to 300 ºF | -54 to 149 ºC
Specifications Type
Solenoid Valve
Specifications Voltage
110 VAC
