Atkomatic 6000 Series Solenoid Valve
Atkomatic 6000 Series Solenoid Valve
SKU:ATK-c6e0d5
High-performance medium pressure solenoid valve with bronze body, suitable for gas media, featuring Viton® seals and compliant coil insulation. Ideal for institutional procurement.
Regular price
$249.99
Regular price
Sale price
$249.99
Unit price
per
Initiate Order
Atkomatic 6000 Series Solenoid Valve
$249.99
Quantity: 1
Claim Your Seller Account
Atkomatic 6000 Series Solenoid Valve
$249.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Atkomatic 6000 Series Solenoid Valve is a high-performance bronze valve designed for medium pressure applications. With a pressure range of 5 to 500 psig and operating temperatures from -15 to 400°F, this valve is versatile for a variety of fluid media types, including gas. It features a Viton® seat and seal material, ensuring reliability and durability. The valve is available in normally closed configuration, with a 1/4 inch female NPT connection size, making it suitable for a wide range of industrial settings. With compliant coil insulation ratings and compact dimensions, the Atkomatic 6000 Series Solenoid Valve is a robust choice for institutional and government procurement needs.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Specifications Body Material
Bronze
Specifications Coil Housing
Standard
Specifications Coil Insulation Rating
Class B (155° C)
Specifications Coil Type
Single Wound Molded
Specifications Connection Size
1/4 in
Specifications Connection Type
Female NPT
Specifications Cv
1.40
Specifications Dim X
7 1/8 in
Specifications Dim Y
6 1/4 in
Specifications Dim Z
2.6875 in
Specifications Fluid Media Type
Gas
Specifications Main Seat Orifice
.375 in
Specifications Operating Pressure
5 to 500 psig
Specifications Position Of Valve De Energized
Normally Closed
Specifications Seat Seal Material
Viton®
Specifications Series
6000
Specifications Temperature Range
-15 to 400 ºF | -29 to 204 ºC
Specifications Type
Solenoid Valve
Specifications Voltage
110 VAC
