The Atkomatic 6000 Series Solenoid Valve is a reliable solution for medium pressure applications, with pressures up to 1500 psig. Constructed from high-quality bronze, this valve is suitable for gases and liquids, including steam and cryogenic substances. With a temperature range from -65 to 300°F, it offers versatility in various environments. Featuring a variety of seat seal materials and coil options, this valve provides customizable options to meet specific fluid requirements. Additionally, the valve is compliant with industry standards for institutional purchases, ensuring quality and reliability for government procurement.
Product Specifications
Specifications Body Material
Bronze
Specifications Coil Housing
Standard
Specifications Coil Insulation Rating
Class B (155° C)
Specifications Coil Type
Single Wound Molded
Specifications Connection Size
1 in
Specifications Connection Type
Female NPT
Specifications Cv
9.5
Specifications Dim X
8.25 in
Specifications Dim Y
7 in
Specifications Dim Z
4 in
Specifications Fluid Media Type
Gas
Specifications Main Seat Orifice
1 in
Specifications Operating Pressure
5 to 500 psig
Specifications Position Of Valve De Energized
Normally Closed
Specifications Seat Seal Material
EPR
Specifications Series
6000
Specifications Temperature Range
-65 to 300 ºF | -54 to 149 ºC
Specifications Type
Solenoid Valve
Specifications Voltage
110 VAC
